24 ft 11 in Lift Height (Forks Up)
600 lbs Max. Load Capacity (14 in. load center)
368 lbs Weight

ML25I

The ML25I industrial material lift is dependably rugged. This robust material lift is designed to withstand the demands of the rental industry. Its reliable construction is also narrow enough to fit through standard doorways. A spring-actuated locking system provides quick and easy deployment and stowage.

Specifications

Lift height (forks up)
24 ft 11 in
Lift height (forks down)
23 ft 2 in
Stowed width
30.5 in
Stabilizer width
64 in
Stowed length
6 ft 5 in
Operating length
6 ft 3 in
Fork width (outside)
23 in
Fork length
30 in
Stowed height
6 ft 2 in
Ground clearance
2.5 in
Max. load capacity (14 in. load center)
600 lbs
Max. load capacity (24 in. load center)
400 lbs
Max. load capacity (42 in. load center)
200 lbs
Min. load height
6 in
Winch (high speed)
4 cranks/ft
Winch (low speed)
15 cranks/ft
Weight
368 lbs

Specifications subject to change without notice. The equipment hereunder have been subject to limited testing, and any performance specifications and representations are the result of limited testing. Photos and diagrams are shown for illustrative purposes only. Snorkel makes no warranty, representation, or guarantee regarding the information contained herein or the suitability of its equipment for any particular purpose. It is the Buyer’s responsibility to independently determine suitability of any equipment or parts, and to test and verify the same. Refer to appropriate Snorkel operator’s manual for detailed instructions on the proper use and maintenance.

Last Updated
03/2020

Standard Features

  • Stabilisers with non-marking swivel casters
  • Non-marking transport/loading wheels
  • Dual handle, two-speed shift-on-the-fly winch
  • Metal cable pulleys with sealed bearings
  • Heavy-gauge aluminium extrusions
  • Heavy-duty, non-marking casters
  • Quick-fold stabilisers
  • Crane attachment point
  • Cable guard
  • Mast brake
  • 2 year parts & labour, 5 year structural warranty

Options

  • Special paint colours (one colour)
  • Adjustable forks
  • Fork extensions
  • Boom
  • Pipe cradle
  • Load platform
