SR9244
9,260 lbs Lift Capacity
44 ft 4 in Lift Height
24,581 lbs Weight

SR9244

The Snorkel SR9244 rough terrain telehandler delivers powerful performance. Designed for durability, this telehandler is fitted with powerful 4-wheel drive, crab steering and outriggers as standard. Rugged and robust, the SR9244/SR1442 is ideal for construction applications.

Specifications

Max. lift capacity
9,260 lbs
Max. lift height
44 ft 4 in
Max. forward reach
31 ft 2 in
Length to fork face
21 ft 2 in
Wheelbase
9 ft 8 in
Overall width
7 ft 6 in
Stowed height
8 ft 5 in
Ground clearance
1 ft 2 in
Hydraulic flow (per minute)
32 gallons
Hydraulic pressure
3,336 psi
Hydraulic oil capacity
39.5 gallons
Fuel capacity
31.7 gallons
Raise / lower time
13 / 9.55 sec
Outside turning radius
13 ft 8 in
Tires
405/70 - 24
Power source
Deutz TLD 3.6L Tier 4 Final diesel 100hp
Weight
24,581 lbs
Frame leveling
11°

Specifications subject to change without notice. The equipment hereunder have been subject to limited testing, and any performance specifications and representations are the result of limited testing. Photos and diagrams are shown for illustrative purposes only. Snorkel makes no warranty, representation, or guarantee regarding the information contained herein or the suitability of its equipment for any particular purpose. It is the Buyer’s responsibility to independently determine suitability of any equipment or parts, and to test and verify the same. Refer to appropriate Snorkel operator’s manual for detailed instructions on the proper use and maintenance.

Last Updated
02/2019

Standard Features

  • Deutz Tier 4 Final diesel
  • Enclosed cab with heat & air conditioning
  • Front and rear led work lights
  • Window wipers
  • Running lights
  • Manual pintle hitch
  • Backup alarm
  • Boom work lights (2)
  • Peb electrical boom socket
  • Constant front hydraulic flow
  • USA block heater plug
  • B class carriage adapter
  • Hydraulic attachment quick disconnects
  • 2 Year parts & labor, 5 year structural warranty

Options

  • Font and rear work LED lights
