TB86J
92 ft Working Height
500 lbs Platform Capacity
38,690 lbs Weight

TB86J

The Snorkel TB86J telescopic boom lift delivers precise reach. The TB86J balances compact dimensions and high reach for full versatility on the jobsite. An added jib offers flexibility and even more outreach where needed most.

Specifications

Max. working height
92 ft
Max. platform height
86 ft
Max. horizontal reach
78 ft 3 in
Platform size
8 ft x 3 ft
Overall length
42 ft 3 in
Overall width
8 ft 6 in
Stowed height
9 ft 6 in
Ground clearance
13 in
Platform capacity (SWL)
500 lbs
Max. drive height
86 ft
Max. wind speed
28 mph
Max. drive speed (elevated)
0.6 mph
Max. drive speed (stowed)
3.0 mph
Raise / lower time
230 / 210 sec
Gradeability
40%
Jib length
6 ft 6 in
Jib arc
135° (+70°/-65°)
Platform rotation
150°
Superstructure rotation
360° continuous
Tailswing
78.5 in
Inside turning radius
7 ft 10 in
Outside turning radius
15 ft 6 in
Tires
15 x 625 foam filled lug
Controls
Proportional joystick
Drive system
4 wheel drive
Power source
Kubota V2403 65hp diesel - Tier 4 Final
Weight
38,690 lbs

Specifications subject to change without notice. The equipment hereunder have been subject to limited testing, and any performance specifications and representations are the result of limited testing. Photos and diagrams are shown for illustrative purposes only. Snorkel makes no warranty, representation, or guarantee regarding the information contained herein or the suitability of its equipment for any particular purpose. It is the Buyer’s responsibility to independently determine suitability of any equipment or parts, and to test and verify the same. Refer to appropriate Snorkel operator’s manual for detailed instructions on the proper use and maintenance.

Last Updated
02/2019

Standard Features

  • Snorkel GuardTM secondary guarding system
  • Four wheel drive, steer and crab steer
  • Hydraulic platform rotation
  • 360° continuous turntable rotation
  • Drive motion alarm
  • Flashing amber light
  • Foam filled lug tires
  • Proportional drive, boom lift, swing & extend
  • Rheostat control for jib & platform level
  • Power line to platform
  • 5° tilt alarm
  • Tri-entry platform
  • Dual lanyard attachment points
  • Hour meter & on-board diagnostics display
  • Horn
  • 2 year parts & labor, 5 year structural warranty

Options

  • Special paint colors
  • Airline to platform
  • AC generator 110V/240V 2kW
  • Non-marking tires
  • Cold weather package
  • Extreme cold weather package
  • Extreme environment package
  • Light package
  • Tow kit
  • Dual fuel
  • Glazier package
  • Utility package
  • 12k Generator package
  • 12k Generator/Welder package
  • Environmental hydraulic oil
  • Tool tray
  • CSA compliant
