660SJ
72 ft Working Height
27,300 lbs Weight

660SJ

The Snorkel 660SJ mid-sized telescopic boom lift is rugged and robust for all terrains. Built to last, a constant 4-wheel drive delivers outstanding rough terrain performance. For full reach on any jobsite, operators benefit from all-proportional hydraulics and a jib for added flexibility.

Specifications

Max. working height
Max. platform height
Max. horizontal reach
Platform size
Overall width
Transport width
Overall length
Transport length
Stowed height
Transport height
Ground clearance
Platform capacity - unrestricted
Platform capacity - restricted
Max. drive height
Max. wind speed
Max. drive speed (stowed)
Max. drive speed (elevated)
Jib length
Jib arc
Platform rotation
Superstructure rotation
Tailswing
Raise/lower time
Gradeability
Inside turning radius
Outside turning radius
Tires
Controls
Drive system
Power source
Auxiliary power unit
Weight
Max. working height (ANSI metric)
Max. platform height (ANSI metric)
Max. horizontal reach (ANSI metric)
Platform size (ANSI metric)
Overall width (ANSI metric)
Transport width (ANSI metric)
Overall length (ANSI metric)
Transport length (ANSI metric)
Stowed Height (ANSI Metric)
Transport height (ANSI metric)
Ground clearance (ANSI metric)
Platform capacity - unrestricted (ANSI metric)
Platform capacity - restricted (ANSI metric)
Max. wind speed (ANSI metric)
Max. drive speed (stowed) (ANSI metric)
Max. drive speed (elevated) (ANSI metric)
Jib length (ANSI metric)
Jib arc (ANSI metric)
Platform rotation (ANSI metric)
Superstructure rotation (ANSI metric)
Tailswing (ANSI metric)
Raise/lower time (ANSI Metric)
Gradeability (ANSI metric)
Inside turning radius (ANSI metric)
Outside turning radius (ANSI metric)
Tires (ANSI metric)
Controls (ANSI metric)
Drive system (ANSI metric)
Power source (ANSI Metric)
Auxiliary power unit (ANSI metric)
Weight (ANSI Metric)
Max. working height (CE Imperial)
Max. platform height (CE imperial)
Max. horizontal reach (CE imperial)
Platform size (CE imperial)
Transport width (CE imperial)
Overall width (CE imperial)
Overall length (CE imperial)
Transport length (CE imperial)
Stowed Height (CE Imperial)
Transport height (CE imperial)
Ground clearance (CE imperial)
Platform capacity - unrestricted (CE imperial)
Platform capacity - restricted (CE imperial)
Max. wind speed (CE imperial)
Max. drive height (CE imperial)
Max. drive speed (stowed) (CE imperial)
Max. drive speed (elevated) (CE imperial)
Jib length (CE imperial)
Jib arc (CE imperial)
Platform rotation (CE imperial)
Superstructure rotation (CE imperial)
Tailswing (CE imperial)
Raise/lower time (CE Imperial)
Gradeability (CE imperial)
Inside turning radius (CE imperial)
Outside turning radius (CE imperial)
Tires (CE imperial)
Drive system (CE imperial)
Power source (CE Imperial)
Auxiliary power unit (CE imperial)
Weight (CE imperial)
Max. platform height (CE metric)
Max. working height (CE metric)
Platform size (CE metric)
Overall width (CE metric)
Transport width (CE metric)
Overall length (CE metric)
Transport length (CE metric)
Stowed Height (CE Metric)
Transport height (CE metric)
Ground clearance (CE metric)
Platform capacity - unrestricted (CE metric)
Platform capacity - restricted (CE metric)
Max. wind speed (CE metric)
Max. drive speed (stowed) (CE metric)
Max. drive speed (elevated) (CE metric)
Jib length (CE metric)
Jib arc (CE metric)
Platform rotation (CE metric)
Superstructure rotation (CE metric)
Raise/lower time (CE Metric)
Inside turning radius (CE metric)
Outside turning radius (CE metric)
Tires (CE metric)
Controls (CE metric)
Drive system (CE metric)
Power source (CE Metric)
Weight (CE Metric)
Max. working height
72 ft
Max. platform height
66 ft 7 in
Max. horizontal reach
59 ft 1 in
Platform size
8 ft x 3 ft
Stowed height
8 ft 3 in
Ground clearance
13.5 in
Platform capacity - unrestricted
600 lbs
Platform capacity - restricted
n/a
Overall width
8 ft 1 in
Overall length
34 ft 2 in
Max. wind speed
28 mph
Max. drive height
66 ft
Max. drive speed (elevated)
0.6 mph
Max. drive speed (stowed)
3.5 mph
Raise / lower time
50 / 50 sec
Gradeability
45%
Jib length
6 ft 6 in
Jib arc
135°
Platform rotation
150°
Superstructure rotation
360° continuous
Tailswing
47 in
Inside turning radius
10 ft 1 in
Outside turning radius
17 ft 1 in
Tires
355/55 D625 foam filled lug
Controls
Proportional drive, raise, slew, extend, jib and platform rotate
Drive system
4 wheel drive
Power source
Cummins 65hp turbo diesel - Tier 4 Final
Auxiliary power unit
12V DC
Weight
27,300 lbs

Specifications subject to change without notice. The equipment hereunder have been subject to limited testing, and any performance specifications and representations are the result of limited testing. Photos and diagrams are shown for illustrative purposes only. Snorkel makes no warranty, representation, or guarantee regarding the information contained herein or the suitability of its equipment for any particular purpose. It is the Buyer’s responsibility to independently determine suitability of any equipment or parts, and to test and verify the same. Refer to appropriate Snorkel operator’s manual for detailed instructions on the proper use and maintenance.

Last Updated
02/2019

Standard Features

  • Snorkel GuardTM secondary guarding system
  • 6ft 6in, 135° jib (660SJ only)
  • Oscillating axle (8 ̋ of oscillation)
  • Hydraulic platform rotation
  • Four wheel drive
  • All proportional controls
  • Swing-out engine tray
  • Motion alarm
  • Horn
  • Hour meter & on-board diagnostics display
  • Power line to platform
  • Tilt alarm & cut-out
  • DC emergency operation
  • Tri-entry platform
  • Flashing amber light
  • Platform overload system
  • 2 year parts & labor, 5 year structural warranty

Options

  • Special paint colors
  • Airline to platform
  • AC generator 110V/240V 2kW
  • Non-marking tires
  • Dual fuel
  • Aircraft package
  • Deluxe aircraft package
  • Cold weather package
  • Extreme cold weather package
  • Extreme environment package
  • Tow kit
  • Glazier package
  • Light package
  • 10k Generator package (small g)
  • 10k Generator/welder package (small g & w)
  • Environmental hydraulic oil
  • CSA compliant



Downloads

Specification Sheet (ANSI Metric)

English Français

Specification Sheet (ANSI Imperial)

English

Product Range Multifold (ANSI)

English Español
