Ultra Stable - Snorkel UL25
30 ft 11 in Working Height
350 lbs Platform Capacity
859 lbs Weight (AC)

UL25

The Snorkel UL25 push-around mast lift is a lightweight and low cost indoor work platform. Designed with a small footprint and outriggers as standard, one person can easily set up and operate the UL25 for quick access.

Specifications

Max. working height
Max. platform height
Platform length
Platform width
Stabilizer footprint
Overall width
Overall length
Stowed height
Tilt back length
Tilt back height
Platform capacity (SWL)
Max. wind speed
Raise/lower time
Wheels
Controls
Wall access
Power source (AC)
Power source (DC)
Weight (AC)
Weight (DC)
Max. working height (ANSI metric)
Max. platform height (ANSI metric)
Platform length (ANSI metric)
Platform width (ANSI metric)
Stabilizer footprint (ANSI metric)
Overall width (ANSI metric)
Overall length (ANSI metric)
Stowed Height (ANSI Metric)
Tilt back length (ANSI metric)
Tilt back height (ANSI metric)
Platform capacity (SWL - ANSI metric)
Max. wind speed (ANSI metric)
Raise/lower time (ANSI Metric)
Controls (ANSI metric)
Wall access (ANSI metric)
Power source (AC) (ANSI metric)
Power source (DC) (ANSI metric)
Weight (AC) (ANSI metric)
Weight (DC) (ANSI metric)
Max. working height (CE Imperial)
Max. platform height (CE imperial)
Platform length (CE imperial)
Platform width (CE imperial)
Stabilizer footprint (CE imperial)
Overall width (CE imperial)
Overall length (CE imperial)
Stowed Height (CE Imperial)
Tilt back length (CE imperial)
Platform capacity (SWL - CE Imperial)
Max. wind speed (CE imperial)
Raise/lower time (CE Imperial)
Wall access (CE imperial)
Power source (AC) (CE imperial)
Power source (DC) (CE imperial)
Weight (AC) (CE imperial)
Weight (DC) (CE imperial)
Max. working height (CE metric)
Max. platform height (CE metric)
Platform length (CE metric)
Stabilizer footprint (CE metric)
Overall width (CE metric)
Overall length (CE metric)
Stowed Height (CE Metric)
Tilt back length (CE metric)
Platform capacity (SWL - CE Metric)
Max. wind speed (CE metric)
Raise/lower time (CE Metric)
Controls (CE metric)
Wall access (CE metric)
Power source (AC) (CE metric)
Power source (DC) (CE metric)
Weight (AC) (CE metric)
Weight (DC) (CE metric)
Max. working height
30 ft 11 in
Max. platform height
24 ft 11 in
Platform length
22 in
Platform width
26 in
Stabilizer footprint
6 ft 10 in x 6 ft 6 in
Stowed height
6 ft 6 in
Tilt back length
8 ft 6 in
Tilt back height
6 ft 5 in
Platform capacity (SWL)
350 lbs
Overall width
2 ft 5 in
Overall length
4 ft 2 in
Max. wind speed
0 mph
Raise / lower time
43 / 23 sec
Wheels
9 in x 2.5 in rear, 6 in casters fron
Controls
Push button
Wall access
14 in
Power source (AC)
120/220V AC 50HZ
Power source (DC)
1 x 12V 105 Ah battery
Weight (AC)
859 lbs
Weight (DC)
926 lbs

Specifications subject to change without notice. The equipment hereunder have been subject to limited testing, and any performance specifications and representations are the result of limited testing. Photos and diagrams are shown for illustrative purposes only. Snorkel makes no warranty, representation, or guarantee regarding the information contained herein or the suitability of its equipment for any particular purpose. It is the Buyer’s responsibility to independently determine suitability of any equipment or parts, and to test and verify the same. Refer to appropriate Snorkel operator’s manual for detailed instructions on the proper use and maintenance.

Last Updated
02/2019

Standard Features

  • Patented girder lock telescopic mast system
  • Integrated tilt-back system
  • Ground level entry
  • EZ Loader system for transport
  • Outrigger interlock indicators
  • Integrated battery charger (DC only)
  • Non-marking wheels & casters
  • 2 year parts & labor, 5 year structural warranty

Options

  • Special paint colors
  • Tool tray
  • Laser locator
  • Environmental hydraulic oil
