SR630
6,000 lbs Lift Capacity
30 ft 7 in Lift Height
13,700 lbs Weight

SR630

The Snorkel SR630 rough terrain telehandler is lightweight for ultimate maneuverability on the job site. This compact telehandler features a 6° chassis frame sway and a boom lift point for safer handling of suspended loads.

Specifications

Max. lift capacity
6,000 lbs
Max. lift height
30 ft 7 in
Max. forward reach
18 ft 5 in
Length to fork face
16 ft 3 in
Wheelbase
116 in
Overall width
78 in
Stowed height
83.5 in
Ground clearance
14 in
Hydraulic flow (per minute)
26 gallons
Hydraulic pressure
3,500 psi
Hydraulic oil capacity
50 gallons
Fuel capacity
26 gallons
Outside turning radius
11 ft
Tires
12.5/80-18 Pneumatic
Power source
Deutz TLD 2.9L 74hp (T4F)
Weight
13,700 lbs

Specifications subject to change without notice. The equipment hereunder have been subject to limited testing, and any performance specifications and representations are the result of limited testing. Photos and diagrams are shown for illustrative purposes only. Snorkel makes no warranty, representation, or guarantee regarding the information contained herein or the suitability of its equipment for any particular purpose. It is the Buyer’s responsibility to independently determine suitability of any equipment or parts, and to test and verify the same. Refer to appropriate Snorkel operator’s manual for detailed instructions on the proper use and maintenance.

Last Updated
02/2019

Standard Features

  • 360° operator visibility
  • Large cross section boom w/wear pads
  • Easy service access
  • 6° chassis frame sway
  • Steel hydraulic & fuel tanks
  • Plastic dash with display screen
  • Linde hydrostatic 2 speed transmission
  • Front and rear limited slip axles
  • Plastic fenders
  • Easy cab mounted grab handles
  • Tier 4 final compliant engine
  • Solid steel plate chassis
  • Melonite pins
  • Machine lift points
  • Deutz TD 2.9L 74hp (T4F)
  • 2 year parts & labor, 5 year structural warranty

Options

  • Flashing amber strobe
  • Boom work lights - LED
  • Rear cab work lights - LED
  • Tail, turn, running & brake lights Fuel cap-locking
  • Enclosed cab clear glass
  • Machine lift points (4)
  • Special paint (excluding cab)
  • Special paint (including cab)
  • Flashing green strobe
  • Backup camera
  • Secondary backup camera
  • Cold weather synthetic oil
  • Swivel hook
  • Hydraulic tank heater
  • Battery heater tray
  • Universal skidsteer attachment
