SR626
5,732 lbs Lift Capacity
19 ft Lift Height
10,360 lbs Weight

SR626

The Snorkel SR626 compact rough terrain telehandler delivers top performance in a compact design. Featuring full-time 4-wheel drive, power assisted steering and proportional joystick, the telehandler is packed with power and precision to lift materials in any application.

Specifications

Max. lift capacity
Max. lift height
Max. forward reach
Stowed height
Length to fork face
Wheelbase
Ground clearance
Hydraulic flow (per minute)
Hydraulic pressure
Hydraulic oil capacity
Fuel capacity
Outside turning radius
Tires
Power source
Weight
Max. lift capacity (CE imperial)
Max. lift height (CE imperial)
Stowed Height (CE Imperial)
Length to fork face (CE imperial)
Wheelbase (CE imperial)
Ground clearance (CE imperial)
Hydraulic flow (per minute) (CE imperial)
Hydraulic pressure (CE imperial)
Hydraulic oil capacity (CE imperial)
Fuel capacity (CE imperial)
Outside turning radius (CE imperial)
Tires (CE imperial)
Power source (CE Imperial)
Weight (CE imperial)
Max. lift capacity (CE metric)
Max. lift height (CE metric)
Max. forward reach (CE metric)
Stowed Height (CE Metric)
Length to fork face (CE metric)
Wheelbase (CE metric)
Ground clearance (CE metric)
Hydraulic flow (per minute) (CE metric)
Hydraulic pressure (CE metric)
Hydraulic oil capacity (CE metric)
Fuel capacity (CE metric)
Outside turning radius (CE metric)
Overall width
Tires (CE metric)
Power source (CE Metric)
Weight (CE Metric)
Overall length
Max. lift capacity
5,732 lbs
Max. lift height
19 ft
Max. forward reach
10 ft 4 in
Stowed height
6 ft 4 in
Length to fork face
13 ft 3 in
Wheelbase
8 ft 3 in
Ground clearance
9 in
Hydraulic flow (per minute)
18.5 gallons
Hydraulic pressure
3,336 psi
Hydraulic oil capacity
18.5 gallons
Fuel capacity
21 gallons
Overall width
6 ft 2 in
Overall length
13 ft 9 in
Outside turning radius
10 ft 8 in
Tires
12 x 16.5
Power source
Yanmar 51.7kw Tier 4 Final diesel
Weight
10,360 lbs

Specifications subject to change without notice. The equipment hereunder have been subject to limited testing, and any performance specifications and representations are the result of limited testing. Photos and diagrams are shown for illustrative purposes only. Snorkel makes no warranty, representation, or guarantee regarding the information contained herein or the suitability of its equipment for any particular purpose. It is the Buyer’s responsibility to independently determine suitability of any equipment or parts, and to test and verify the same. Refer to appropriate Snorkel operator’s manual for detailed instructions on the proper use and maintenance.

Last Updated
02/2018

Standard Features

  • Easy access to components for servicing
  • Full time 4 wheel drive
  • 4 wheel steer
  • Selectable front, crab & coordinated steering modes
  • Auxillary hydraulic circuit on the boom
  • Variable speed hydrostatic drive
  • Fender (set of 4)
  • Fully enclosed cab
  • Proportional joystick controls
  • Adjustable steering column
  • Illuminated gauge and switch panels
  • Color LCD display with machine & engine diagnostics
  • Adjustable suspension seat
  • Flashing beacon
  • Road lights
  • 2 year parts & labor, 5 year structural warranty

Options

  • Work lights on boom (2)
  • Font and rear work LED lights
