SR5719
5,732 lbs Lift Capacity
19 ft Lift Height
10,360 lbs Weight

SR5719

The Snorkel SR5719 compact rough terrain telehandler delivers top performance in a compact design. Featuring full-time 4-wheel drive, power assisted steering and proportional joystick, the telehandler is packed with power and precision to lift materials in any application.

Specifications

Max. lift capacity
Max. lift height
Max. forward reach
Stowed height
Length to fork face
Wheelbase
Ground clearance
Hydraulic flow (per minute)
Hydraulic pressure
Hydraulic oil capacity
Fuel capacity
Outside turning radius
Tires
Power source
Weight
Max. lift capacity (ANSI metric)
Max. lift height (ANSI metric)
Max. forward reach (ANSI metric)
Stowed Height (ANSI Metric)
Length to fork face (ANSI metric)
Wheelbase (ANSI metric)
Ground clearance (ANSI metric)
Hydraulic flow (per minute) (ANSI metric)
Hydraulic pressure (ANSI metric)
Hydraulic oil capacity (ANSI metric)
Fuel capacity (ANSI metric)
Outside turning radius (ANSI metric)
Tires (ANSI metric)
Power source (ANSI Metric)
Weight (ANSI Metric)
Max. lift capacity
5,732 lbs
Max. lift height
19 ft
Max. forward reach
10 ft 4 in
Stowed height
6 ft 4 in
Length to fork face
13 ft 3 in
Wheelbase
8 ft 3 in
Ground clearance
9 in
Hydraulic flow (per minute)
18.5 gallons
Hydraulic pressure
3,336 psi
Hydraulic oil capacity
18.5 gallons
Fuel capacity
21 gallons
Outside turning radius
10 ft 8 in
Tires
12 x 16.5
Power source
Yanmar 70.3kp - Tier 4F diesel
Weight
10,360 lbs

Specifications subject to change without notice. The equipment hereunder have been subject to limited testing, and any performance specifications and representations are the result of limited testing. Photos and diagrams are shown for illustrative purposes only. Snorkel makes no warranty, representation, or guarantee regarding the information contained herein or the suitability of its equipment for any particular purpose. It is the Buyer’s responsibility to independently determine suitability of any equipment or parts, and to test and verify the same. Refer to appropriate Snorkel operator’s manual for detailed instructions on the proper use and maintenance.

Last Updated
02/2019

Standard Features

  • Easy access to components for servicing
  • Full time 4 wheel drive
  • 4 wheel steer
  • Selectable front, crab & coordinated steering modes
  • Auxiliary hydraulic circuit on the boom
  • Variable speed hydrostatic drive
  • Fully enclosed cab with air conditioning
  • Proportional joystick
  • Illuminated gauge and switch panels
  • Color LCD display with machine & engine diagnostics
  • Adjustable suspension seat
  • Flashing beacon
  • Road lights
  • Block heater
  • Boom work lights (2)
  • Constant flow
  • 2 year parts & labor, 5 year structural warranty

Options

  • Work lights on boom (2)
  • Front and rear work LED lights
