Straight on every level - Snorkel SL30SL
35 ft 4 in Working Height
1,300 lbs Platform Capacity
7,495 lbs Weight

SL30SL

The Snorkel SL30SL Speed Level is the largest in the line of sigma boom lifts. Automatic self-leveling without outriggers offers a stable platform on gradients of up to 50%. Drivable at full height on powerful 4-wheel drive, the SL30SL tackles all terrains with ease, even on compound slopes.

Specifications

Max. working height
35 ft 4 in
Max. platform height
29 ft 4 in
Platform size (stowed)
5 ft 8 in x 13 ft 11 in
Platform size (extended)
n/a
Overall length
14 ft 1 in
Overall width
7 ft
Min. height (guardrails folded)
65 in
Stowed height
8 ft 6 in
Axle ground clearance
7.6 in
Chassis ground clearance
65 in
Platform capacity (SWL)
1,300 lbs
Max. drive height
29 ft 4 in
Max. wind speed
28 mph
Max. drive speed (elevated)
0.5 mph
Max. drive speed (stowed)
4.0 mph
Raise / lower time
24 / 36 sec
Gradeability
50%
Max. leveling (front to rear)
Max. leveling (side to side)
13°
Inside turning radius
12 ft 10 in
Outside turning radius
18 ft 6 in
Tires
26 x 12.00 - 12 foam filled
Controls
Proportional joystick
Drive system
4 wheel drive with hydraulic motors & flow dividers
Power source
Kubota D-902 water-cooled diesel engine - Tier 4 Final
Weight
7,495 lbs

Specifications subject to change without notice. The equipment hereunder have been subject to limited testing, and any performance specifications and representations are the result of limited testing. Photos and diagrams are shown for illustrative purposes only. Snorkel makes no warranty, representation, or guarantee regarding the information contained herein or the suitability of its equipment for any particular purpose. It is the Buyer’s responsibility to independently determine suitability of any equipment or parts, and to test and verify the same. Refer to appropriate Snorkel operator’s manual for detailed instructions on the proper use and maintenance.

Last Updated
01/2019

Standard Features

  • Automatic powered platform leveling
  • Powerful 4 wheel drive
  • Oscillating front axle
  • High grip, open tread deck
  • Descent alarm
  • High grip, all-terrain tires
  • Dual multi-disc brakes
  • Proportional controls
  • Power line to platform
  • Fold-down guardrails
  • All motion alarm
  • Hour meter & on-board diagnostics display
  • Horn
  • 2 year parts & labor, 5 year structural warranty

Options

  • Special paint colors
  • Diesel exhaust scrubber
  • Flashing amber light
  • Tunnel package
  • Environmental hydraulic oil
  • Hydraulic generator 110/240V 2kW
  • Platform overload system
  • Non-marking tyres
