SL26SL
31 ft 6 in Working Height
1,500 lbs Platform Capacity
7,826 lbs Weight

SL26SL

The Snorkel SL26SL Speed Level is the original sigma boom lift. Climbing gradients up to 50% and featuring automatic self-leveling without outriggers, it offers superior stability. This Speed Level also features an extension deck for additional outreach. With superb ground clearance and powerful 4-wheel drive, the SL26SL can handle any jobsite.

Specifications

Max. working height
Max. platform height
Platform size (stowed)
Platform size (extended)
Overall width
Overall length
Stowed height
Min. height (guardrails folded)
Chassis ground clearance
Axle ground clearance
Platform capacity (SWL)
Max. wind speed
Max. drive height
Max. drive speed (stowed)
Max. drive speed (elevated)
Raise/lower time
Gradeability
Max. leveling (front to rear)
Max. leveling (side to side)
Inside turning radius
Outside turning radius
Tires
Controls
Drive system
Power source
Weight
Max. working height (ANSI metric)
Max. platform height (ANSI metric)
Platform size (stowed) (ANSI metric)
Platform size (extended) (ANSI metric)
Overall width (ANSI metric)
Overall length (ANSI metric)
Stowed Height (ANSI Metric)
Min. height (guardrails folded) (ANSI metric)
Chassis ground clearance (ANSI metric)
Axle ground clearance (ANSI metric)
Platform capacity (SWL - ANSI metric)
Max. wind speed (ANSI metric)
Max. drive height (ANSI metric)
Max. drive speed (stowed) (ANSI metric)
Max. drive speed (elevated) (ANSI metric)
Raise/lower time (ANSI Metric)
Gradeability (ANSI metric)
Max. leveling (front to rear) (ANSI metric)
Max. leveling (side to side) (ANSI metric)
Inside turning radius (ANSI metric)
Outside turning radius (ANSI metric)
Tires (ANSI metric)
Controls (ANSI metric)
Drive system (ANSI metric)
Power source (ANSI Metric)
Weight (ANSI Metric)
Max. working height (CE Imperial)
Max. platform height (CE imperial)
Platform size (stowed) (CE imperial)
Platform size (extended) (CE imperial)
Overall width (CE imperial)
Overall length (CE imperial)
Stowed Height (CE Imperial)
Min. height (guardrails folded) (CE imperial)
Chassis ground clearance (CE imperial)
Axle ground clearance (CE imperial)
Platform capacity (SWL - CE Imperial)
Max. wind speed (CE imperial)
Max. drive height (CE imperial)
Max. drive speed (stowed) (CE imperial)
Max. drive speed (elevated) (CE imperial)
Raise/lower time (CE Imperial)
Gradeability (CE imperial)
Max. leveling (front to rear) (CE imperial)
Max. leveling (side to side) (CE imperial)
Inside turning radius (CE imperial)
Outside turning radius (CE imperial)
Tires (CE imperial)
Controls (CE imperial)
Drive system (CE imperial)
Power source (CE Imperial)
Weight (CE imperial)
Max. working height (CE metric)
Max. platform height (CE metric)
Platform size (stowed) (CE metric)
Platform size (extended) (CE metric)
Overall width (CE metric)
Overall length (CE metric)
Stowed Height (CE Metric)
Min. height (guardrails folded) (CE metric)
Chassis ground clearance (CE metric)
Axle ground clearance (CE metric)
Platform capacity (SWL - CE Metric)
Max. wind speed (CE metric)
Max. drive height (CE metric)
Max. drive speed (stowed) (CE metric)
Max. drive speed (elevated) (CE metric)
Raise/lower time (CE Metric)
Gradeability (CE metric)
Max. leveling (front to rear) (CE metric)
Max. leveling (side to side) (CE metric)
Inside turning radius (CE metric)
Outside turning radius (CE metric)
Tires (CE metric)
Controls (CE metric)
Drive system (CE metric)
Power source (CE Metric)
Weight (CE Metric)
Max. working height
31 ft 6 in
Max. platform height
25 ft 6 in
Stowed height
8 ft 6 in
Platform size (stowed)
5 ft 8 in x 12 ft
Platform size (extended)
5 ft 8 in x 15 ft
Min. height (guardrails folded)
65 in
Axle ground clearance
7.6 in
Chassis ground clearance
65 in
Platform capacity (SWL)
1,500 lbs
Overall width
7 ft
Overall length
12 ft 5 in
Max. wind speed
28 mph
Max. drive height
25 ft 6 in
Max. drive speed (elevated)
0.5 mph
Max. drive speed (stowed)
4.0 mph
Raise / lower time
21 / 32 sec
Gradeability
50%
Max. leveling (front to rear)
Max. leveling (side to side)
13°
Inside turning radius
12 ft 10 in
Outside turning radius
18 ft 6 in
Tires
26 x 12.00 - 12 foam filled
Controls
Proportional joystick
Drive system
4 wheel drive with hydraulic motors & flow dividers
Power source
Kubota D-902 water-cooled diesel engine - Tier 4 Final
Weight
7,826 lbs

Specifications subject to change without notice. The equipment hereunder have been subject to limited testing, and any performance specifications and representations are the result of limited testing. Photos and diagrams are shown for illustrative purposes only. Snorkel makes no warranty, representation, or guarantee regarding the information contained herein or the suitability of its equipment for any particular purpose. It is the Buyer’s responsibility to independently determine suitability of any equipment or parts, and to test and verify the same. Refer to appropriate Snorkel operator’s manual for detailed instructions on the proper use and maintenance.

Last Updated
01/2019

Standard Features

  • Automatic powered platform leveling
  • Powerful 4 wheel drive
  • Oscillating front axle
  • Roll-out deck extension
  • Descent alarm
  • High grip, all-terrain tires
  • Dual multi-disc brakes
  • Proportional controls
  • Power line to platform
  • Fold-down guardrails
  • All motion alarm
  • Hour meter & on-board diagnostics display
  • Horn
  • 2 year parts & labor, 5 year structural warranty

Options

  • Special paint colors
  • Diesel exhaust scrubber
  • Flashing amber light
  • Tunnel package
  • Environmental hydraulic oil
  • Hydraulic generator 110/240V 2kW
  • Platform overload system
  • Non-marking tyres
