Positively Charged Snorkel SL26RTE
31 ft 6 in Working Height
1,500 lbs Platform Capacity
7,826 lbs Weight

SL26RTE

Long-lasting lithium batteries power the Snorkel SL26RTE all-electric Speed Level. Its quiet performance is balanced by automatic self-leveling capabilities, without outriggers. Equipped with a roll-out deck extension, the SL26RTE features a spacious platform, when extended.

Specifications

Max. working height
31 ft 6 in
Max. platform height
25 ft 6 in
Platform size (stowed)
5 ft 8 in x 12 ft
Platform size (extended)
5 ft 8 in x 15 ft
Overall length
12 ft 5 in
Overall width
7 ft
Min. height (guardrails folded)
65 in
Stowed height
8 ft 6 in
Axle ground clearance
7.6 in
Chassis ground clearance
65 in
Platform capacity (SWL)
1,500 lbs
Max. drive height
25 ft 6 in
Max. wind speed
28 mph
Max. drive speed (elevated)
0.5 mph
Max. drive speed (stowed)
3.3 mph
Raise / lower time
seconds
Gradeability
50%
Max. leveling (front to rear)
Max. leveling (side to side)
13°
Inside turning radius
12 ft 10 in
Outside turning radius
18 ft 6 in
Tires
26 x 12.00 - 12 foam filled
Controls
Digital proportional joystick
Drive system
4 wheel drive with hydraulic motors & flow dividers
Power source
Li-Ion battery with integrated BMS
Weight
7,826 lbs

Specifications subject to change without notice. The equipment hereunder have been subject to limited testing, and any performance specifications and representations are the result of limited testing. Photos and diagrams are shown for illustrative purposes only. Snorkel makes no warranty, representation, or guarantee regarding the information contained herein or the suitability of its equipment for any particular purpose. It is the Buyer’s responsibility to independently determine suitability of any equipment or parts, and to test and verify the same. Refer to appropriate Snorkel operator’s manual for detailed instructions on the proper use and maintenance.

Last Updated
03/2020

Standard Features

  • Two lithium-ion battery systems 222Ah
  • Automatic powered platform levelling
  • Powerful 4 wheel drive
  • Oscillating front axle
  • Roll-out deck extension
  • Descent alarm
  • High grip non-marking all terrain tyres
  • Digital proportional controls
  • Power line to platform
  • Fold-down guardrails
  • All motion alarm
  • Hour meter & on-board diagnostics display
  • Flashing amber light
  • 2000 charging cycles / 2 year* lithium battery warranty
  • 2 year parts & labour, 5 year structural warranty

*whichever comes first. Refer to Snorkel warranty policy for full details, limitations and restrictions. Batteries at the end of their life to be returned to Snorkel for recycling.

Options

  • Special paint colours (1 colours)
  • Special paint colours (2 colours)
  • Environmental hydraulic oil
  • Additional 111Ah battery system
  • Tunnel package
  • Extra range tunnel package (444Ah)
  • Work light package
  • Driving light package
  • Extreme environment package
  • Aluminum platform floor
