31 ft 6 in

Working Height

1,500 lbs

Platform Capacity

7,826 lbs

Weight

SL26RT

The Snorkel SL26RT Speed Level is the original sigma boom lift. Climbing gradients up to 50% and featuring automatic self-leveling without outriggers, it offers superior stability. This Speed Level also features an extension deck for additional outreach. With superb ground clearance and powerful 4-wheel drive, the SL26RT can handle any jobsite.

Max. working height
31 ft 6 in
Max. platform height
25 ft 6 in
Platform size (stowed)
5 ft 8 in x 12 ft
Platform size (extended)
5 ft 8 in x 15 ft
Overall length
12 ft 5 in
Overall width
7 ft
Min. height (guardrails folded)
65 in
Stowed height
8 ft 6 in
Axle ground clearance
7.6 in
Chassis ground clearance
12 in
Platform capacity (SWL)
1,500 lbs
Max. drive height
25 ft 6 in
Max. wind speed
28 mph
Max. drive speed (elevated)
0.5 mph
Max. drive speed (stowed)
4.0 mph
Raise / lower time
21/32 sec
Gradeability
50%
Max. leveling (front to rear)
Max. leveling (side to side)
13°
Inside turning radius
12 ft 10 in
Outside turning radius
18 ft 6 in
Tires
26 x 12.00 – 12 foam filled
Controls
Proportional joystick
Drive system
4 wheel drive with hydraulic motors & flow dividers
Power source
Kubota D-902 water-cooled diesel engine – Tier 4 Final
Weight
7,826 lbs
Specifications subject to change without notice. The equipment hereunder have been subject to limited testing, and any performance specifications and representations are the result of limited testing. Photos and diagrams are shown for illustrative purposes only. Snorkel makes no warranty, representation, or guarantee regarding the information contained herein or the suitability of its equipment for any particular purpose. It is the Buyer’s responsibility to independently determine suitability of any equipment or parts, and to test and verify the same. Refer to appropriate Snorkel operator’s manual for detailed instructions on the proper use and maintenance.
Last Updated
06/2021
  • Automatic powered platform leveling
  • Powerful 4 wheel drive
  • Oscillating front axle
  • Roll-out deck extension
  • Descent alarm
  • High grip, all-terrain tires
  • Dual multi-disc brakes
  • Proportional controls
  • Flashing amber light
  • Power line to platform
  • Fold-down guardrails
  • All motion alarm
  • Hour meter & on-board diagnostics display
  • Horn
  • 2 year parts & labor, 5 year structural warranty
Tunnel Package
Extreme Environment Package
Hydraulic generator 110/240V 2kW
Flashing amber light
Environmental hydraulic oil
Diesel exhaust scrubber
Aluminum platform floor
Special paint colors
Platform overload system
Non-marking tires
