Extreme Capacity Snorkel S9070RT-HC
76 ft Working Height
2,000 lbs Platform Capacity
25,500 lbs Weight

S9070RT-HC

The Snorkel S9070RT-HC is the largest ultra-capacity rough terrain scissor lift in North America. Featuring a twin extension deck as standard, it combines a large platform working area with an extra-wide pallet gate and high lifting capacity for increased productivity on the job. Added rough terrain capabilities makes the S9070RT-HC a premier performer on all jobsites.

Specifications

Max. working height
76 ft
Max. platform height
70 ft
Platform size (stowed)
16 ft x 7 ft 6 in
Platform size (extended)
27 ft x 7 ft 6 in
Deck extension length
4 ft 6 in
Overall length
16 ft
Overall width
7 ft 6 in
Min. height (guardrails folded)
8 ft 5 in
Stowed height
11 ft 3 in
Ground clearance
14 in
Platform capacity (SWL)
2,000 lbs
Max. drive height
44 ft
Max. wind speed
28 mph
Max. drive speed (elevated)
0.6 mph
Max. drive speed (stowed)
4.2 mph
Raise / lower time
70 / 40 seconds
Gradeability
50%
Inside turning radius
8 ft
Outside turning radius
18 ft 6 in
Tires
13 x 36 foam filled
Controls
Proportional joystick
Drive system
4 wheel drive
Power source
Kubota diesel
Weight
25,500 lbs

Specifications subject to change without notice. The equipment hereunder have been subject to limited testing, and any performance specifications and representations are the result of limited testing. Photos and diagrams are shown for illustrative purposes only. Snorkel makes no warranty, representation, or guarantee regarding the information contained herein or the suitability of its equipment for any particular purpose. It is the Buyer’s responsibility to independently determine suitability of any equipment or parts, and to test and verify the same. Refer to appropriate Snorkel operator’s manual for detailed instructions on the proper use and maintenance.

Last Updated
04/2020

Standard Features

  • 4 wheel drive
  • Roll-out deck extension
  • 4 hydraulic stabilizers with automatic leveling
  • Non-marking foam filled tires
  • Proportional controls
  • Power line to platform
  • Platform overload system
  • Drive motion alarm
  • Descent alarm
  • Fold-down guardrails
  • Flashing amber light (x2)
  • Articulating axle
  • Hour meter & on-board diagnostics display
  • Manual lowering valve
  • Dual lanyard attachment points
  • 2 years parts & labor, 5 year structural warranty

Options

  • Special paint colors
  • Hydraulic generator 110V 2kW
  • Hydraulic generator 12kW
  • Nylon spreader pads (set of 4)
  • Environmental hydraulic oil
