Rugged Resilience Snorkel S9043RT
49 ft Working Height
1,500 lbs Platform Capacity
14,000 lbs Weight

S9043RT

The new Snorkel S9043RT high capacity rough terrain scissor lift delivers high performance. Equipped with a spacious roll-out deck, this scissor lift offers excellent lift capacity. Superb terrain capabilities can easily handle tough jobsite conditions on powerful 4-wheel drive. The S9043RT is packed with operator benefits such as saloon-entry gates and swing-out engine trays.

Specifications

Max. working height
49 ft
Max. platform height
16 ft
Platform size (stowed)
11 ft 9 in x 7 ft 6 in
Deck extension length
4 ft 6 in
Overall length
12 ft 1 in
Overall width
7 ft 6 in
Min. height (guardrails folded)
7 ft 2 in
Stowed height
9 ft 10 in
Ground clearance
15 in
Platform capacity (SWL)
1,500 lbs
Max. drive height
43 ft
Max. wind speed
28 mph
Max. drive speed (elevated)
0.6 mph
Max. drive speed (stowed)
4.2 mph
Raise / lower time
50 / 35 seconds
Gradeability
50%
Inside turning radius
6 ft 8 in
Outside turning radius
17 ft 4 in
Tires
12 x 33 foam filled
Controls
Proportional joystick
Drive system
4 wheel drive
Power source
Kubota diesel
Weight
14,000 lbs

Specifications subject to change without notice. The equipment hereunder have been subject to limited testing, and any performance specifications and representations are the result of limited testing. Photos and diagrams are shown for illustrative purposes only. Snorkel makes no warranty, representation, or guarantee regarding the information contained herein or the suitability of its equipment for any particular purpose. It is the Buyer’s responsibility to independently determine suitability of any equipment or parts, and to test and verify the same. Refer to appropriate Snorkel operator’s manual for detailed instructions on the proper use and maintenance.

Last Updated
04/2020

Standard Features

  • 4 wheel drive
  • Single manual roll-out deck extension
  • Non-marking foam filled tires
  • Proportional controls
  • Power line to platform
  • Platform overload system
  • Drive motion alarm
  • Descent alarm
  • Fold-down guardrails
  • Flashing amber light (x2)
  • Locking, articulating axle
  • Hour meter & on-board diagnostics display
  • Manual lowering valve
  • Dual lanyard attachment points
  • 2 years parts & labor, 5 year structural warranty

Options

  • Special paint colors
  • Hydraulic generator 110V 2kW
  • Hydraulic generator 12kW
  • Nylon spreader pads (set of 4)
  • Environmental hydraulic oil
  • Dual extension decks
  • Single powered extension decks
  • Dual powered extension decks
  • 4 hydraulic stabilizers with automatic levelling
