Sizable Strength Snorkel S9033RT rough terrain scissor lift
39 ft Working Height
2,500 lbs Platform Capacity
16,302 lbs Weight (with outriggers)

S9033RT

The new Snorkel S9033RT high capacity rough terrain scissor lift measures up. A spacious roll-out deck extension with superb lift capacity makes it easy to work at height. Excellent ground clearance, a tight inside turning radius and powerful 4-wheel drive tackle rough terrain with ease.

Specifications

Max. working height
39 ft
Max. platform height
33 ft
Platform size (stowed)
12 ft 11 in x 7 ft 6 in
Deck extension length
4 ft 6 in
Overall width
7 ft 6 in
Min. height (guardrails folded)
6 ft 6 in
Stowed height
9 ft
Ground clearance
11 in
Platform capacity (SWL)
2,500 lbs
Max. drive height
32 ft
Max. wind speed
28 mph
Max. drive speed (elevated)
0.6 mph
Max. drive speed (stowed)
4.2 mph
Raise / lower time
45 / 30 seconds
Gradeability
50%
Max. stabilizer leveling (front to rear)
Max. stabilizer leveling (side to side)
12°
Inside turning radius
6 ft 8 in
Outside turning radius
17 ft 4 in
Tires
12 x 33 foam filled
Controls
Proportional joystick
Drive system
4 wheel drive
Power source
Kubota diesel
Weight (without outriggers)
14,876 lbs
Weight (with outriggers)
16,302 lbs

Specifications subject to change without notice. The equipment hereunder have been subject to limited testing, and any performance specifications and representations are the result of limited testing. Photos and diagrams are shown for illustrative purposes only. Snorkel makes no warranty, representation, or guarantee regarding the information contained herein or the suitability of its equipment for any particular purpose. It is the Buyer’s responsibility to independently determine suitability of any equipment or parts, and to test and verify the same. Refer to appropriate Snorkel operator’s manual for detailed instructions on the proper use and maintenance.

Last Updated
06/2021

Standard Features

  • 4 wheel drive
  • Single powered deck extension
  • Foam filled tires
  • Proportional controls
  • Power line to platform
  • Platform overload system
  • Drive motion alarm
  • Descent alarm
  • Fold-down guardrails
  • Flashing amber light (x2)
  • Locking, oscillating axle
  • Hour meter & on-board diagnostics display
  • Manual lowering valve
  • Flashing amber light (x2)
  • Dual lanyard attachment points
  • 2 years parts & labor, 5 year structural warranty

Options

  • Special paint colors
  • Nylon spreader pads (set of 4)
  • Environmental hydraulic oil
  • Dual fuel
  • Cold weather package (block heater + battery warm up)
  • Dual powered extension decks
  • Dual manual extension decks
  • Hydraulic generator 110V 2kW
  • 12kW generator package
  • Non-marking foam filled tires
  • 4 hydraulic stabilizers with automatic levelling
  • Snorkel OnSite™ telematics
