Elevated Power Snorkel S9031RT-HC rough terrain scissor lift
37 ft Working Height
4,000 lbs Platform Capacity
15,000 lbs Weight

S9031RT-HC

The Snorkel S9031RT-HC ultra-capacity rough terrain scissor lift is ideal for heavy lifting. Its robust construction offers best-in-class lift capacity. With a twin extension deck and pallet gate, offering an extra-wide 6.5 ft. (1.9m) opening, tools and materials can be easily lifted. The S9031RT-HC also features excellent off-road capability, suitable for tough environments.

Specifications

Max. working height
37 ft
Max. platform height
31 ft
Platform size (stowed)
16 ft x 7 ft 6 in
Platform size (extended)
25 ft x 7 ft 6 in
Deck extension length
4 ft 6 in
Overall length
16 ft
Overall width
7 ft 6 in
Min. height (guardrails folded)
6 ft 3 in
Stowed height
9 ft 1 in
Ground clearance
14 in
Platform capacity (SWL)
4,000 lbs
Max. drive height
31 ft
Max. wind speed
28 mph
Max. drive speed (elevated)
0.6 mph
Max. drive speed (stowed)
4.2 mph
Raise / lower time
30 / 20 seconds
Gradeability
50%
Max. stabilizer leveling (front to rear)
Max. stabilizer leveling (side to side)
14º
Inside turning radius
8 ft
Outside turning radius
18 ft 6 in
Tires
13 x 36 foam filled
Controls
Proportional joystick
Drive system
4 wheel drive
Power source
Kubota diesel
Weight
15,000 lbs

Specifications subject to change without notice. The equipment hereunder have been subject to limited testing, and any performance specifications and representations are the result of limited testing. Photos and diagrams are shown for illustrative purposes only. Snorkel makes no warranty, representation, or guarantee regarding the information contained herein or the suitability of its equipment for any particular purpose. It is the Buyer’s responsibility to independently determine suitability of any equipment or parts, and to test and verify the same. Refer to appropriate Snorkel operator’s manual for detailed instructions on the proper use and maintenance.

Last Updated
06/2021

Standard Features

  • 4 wheel drive
  • Dual powered extension decks
  • 4 hydraulic stabilizers with automatic leveling
  • Non-marking foam filled tires
  • Proportional controls
  • Foam filled tires
  • Power line to platform
  • Platform overload system
  • Drive motion alarm
  • Descent alarm
  • Locking, oscillating axle
  • Fold-down guardrails
  • Flashing amber light
  • Hour meter & on-board diagnostics display
  • Manual lowering valve
  • Dual lanyard attachment points
  • 2 years parts & labor, 5 year structural warranty

Options

  • Special paint colors
  • Nylon spreader pads (set of 4)
  • Environmental hydraulic oil
  • Dual fuel
  • Non-marking foam filled tires
  • Cold weather package (block heater + battery warm up)
  • Hydraulic generator 110V 2kW
  • 12kW generator package
  • Snorkel OnSite™ telematics
