Electric Efficiency Snorkel S3370RTE
39 ft Working Height
1,000 lbs Platform Capacity
7,980 lbs Weight

S3370RTE

The Snorkel S3370RTE compact rough terrain electric scissor lift is clean and quiet. Powerful 4-wheel drive and long-lasting lithium-ion batteries make this scissor lift highly versatile for outdoor work. It delivers superb terrain capabilities from a compact design to easily navigate tight areas.

Specifications

Max. working height
39 ft
Max. platform height
33 ft
Platform size (stowed)
9 ft 8 in x 5 ft 2 in
Platform size (extended)
13 ft 1 in x 5 ft 2 in
Deck extension length
4 ft
Overall length
11 ft 3 in
Overall width
5 ft 10 in
Min. height (guardrails folded)
6 ft 6 in
Stowed height
9 ft
Ground clearance
13 in
Platform capacity (SWL)
1,000 lbs
Max. drive height
33 ft
Max. wind speed
28 mph
Max. drive speed (elevated)
0.3 mph
Max. drive speed (stowed)
2.8 mph
Raise / lower time
50 / 60 seconds
Gradeability
35%
Max. outrigger levelling (front to rear)
Max. outrigger levelling (side to side)
10°
Inside turning radius
8 ft 10 in
Outside turning radius
16 ft 3 in
Tires
27 x 10.5 - 15 foam filled non marking
Controls
Proportional joystick
Drive system
4 wheel drive
Power source
Li-Ion battery with integrated BMS
Weight
7,980 lbs

Specifications subject to change without notice. The equipment hereunder have been subject to limited testing, and any performance specifications and representations are the result of limited testing. Photos and diagrams are shown for illustrative purposes only. Snorkel makes no warranty, representation, or guarantee regarding the information contained herein or the suitability of its equipment for any particular purpose. It is the Buyer’s responsibility to independently determine suitability of any equipment or parts, and to test and verify the same. Refer to appropriate Snorkel operator’s manual for detailed instructions on the proper use and maintenance.

Last Updated
03/2020

Standard Features

  • Two lithium-ion battery systems 222Ah
  • 4 wheel drive
  • Roll-out deck extension
  • 4 hydraulic stabilizers with automatic leveling
  • Non-marking foam filled tires
  • Proportional controls
  • Power line to platform
  • Platform overload system
  • Drive motion alarm
  • Descent alarm
  • Fold-down guardrails
  • Flashing amber light (x2)
  • Articulating axle
  • Hour meter & on-board diagnostics display
  • Manual lowering valve
  • Dual lanyard attachment points
  • 2000 charging cycles/2 year**
  • lithiumbattery warranty
  • 2 years parts & labor, 5 year structural warranty

**Whichever comes first. Refer to Snorkel warranty policy for full details, limitations and restrictions. Batteries at the end of their life to be returned to Snorkel for recycling.

Options

  • Special paint colors
  • Additional 111Ah battery system
  • Nylon spreader pads (set of 4)
  • Environmental hydraulic oil
