Built for Versatility - Snorkel S2770RT
33 ft Working Height
1,250 lbs Platform Capacity
6,172 lbs Weight

S2770RT

The Snorkel S2770RT compact rough terrain diesel scissor lift is lightweight yet powerful. Equipped with robust 4-wheel drive, it makes easy work of rough terrain. Compact dimensions allow the S2770RT to perform outdoor work in confined spaces. Auto level outriggers and a roll-out deck extension also come as standard.

Specifications

Max. working height
33 ft
Max. platform height
27 ft
Platform size (stowed)
9 ft 8 in x 5 ft 2 in
Platform size (extended)
13 ft 1 in x 5 ft 2 in
Deck extension length
4 ft
Overall length
11 ft
Overall width
5 ft 10 in
Min. height (guardrails folded)
6 ft
Stowed height
8 ft 6 in
Ground clearance
13 in
Platform capacity (SWL)
1,250 lbs
Max. drive height
27 ft
Max. wind speed
28 mph
Max. drive speed (elevated)
0.3 mph
Max. drive speed (stowed)
2.8 mph
Raise / lower time
26 / 30 sec
Gradeability
45%
Max. outrigger levelling (front to rear)
Max. outrigger levelling (side to side)
10°
Inside turning radius
8 ft
Outside turning radius
15 ft 7 in
Tires
27 x 10.5 - 15 non-marking foam filled
Controls
Proportional joystick
Drive system
4 wheel drive
Power source
Kubota D-902 water cooled diesel 22.5 hp - Tier 4 Final
Weight
6,172 lbs

Specifications subject to change without notice. The equipment hereunder have been subject to limited testing, and any performance specifications and representations are the result of limited testing. Photos and diagrams are shown for illustrative purposes only. Snorkel makes no warranty, representation, or guarantee regarding the information contained herein or the suitability of its equipment for any particular purpose. It is the Buyer’s responsibility to independently determine suitability of any equipment or parts, and to test and verify the same. Refer to appropriate Snorkel operator’s manual for detailed instructions on the proper use and maintenance.

Last Updated
02/2019

Standard Features

  • 4 wheel drive
  • Roll-out deck extension
  • 4 hydraulic stabilizers with automatic leveling
  • Non-marking foam filled tires
  • Proportional controls
  • Power line to platform
  • Drive motion alarm
  • Descent alarm
  • Fold-down guardrails
  • Flashing amber light (x2)
  • Articulating axle
  • Hour meter & on-board diagnostics display
  • Manual lowering valve
  • Dual lanyard attachment points
  • 2 years parts & labor, 5 year structural warranty

Options

  • Special paint colors
  • Hydraulic generator 110V 2kW
  • Nylon spreader pads (set of 4)
  • Environmental hydraulic oil
  • Platform overload system
