Long-Lasting Versatility - Snorkel S2770BE
33 ft Working Height
1,250 lbs Platform Capacity
6,834 lbs Weight

S2770BE

The Snorkel S2770BE offers the capabilities of the S2770RT compact rough terrain scissor lift with a bi-energy power system. Highly versatile, use the diesel engine for outdoor work, or switch to zero emission battery power for indoor tasks. Non-marking, high grip tires, a roll-out deck extension and auto-level hydraulic outriggers come as standard.

Specifications

Max. working height
Max. platform height
Platform size (stowed)
Platform size (extended)
Deck extension length
Overall width
Overall length
Stowed height
Min. height (guardrails folded)
Ground clearance
Platform capacity (SWL)
Max. drive height
Max. drive speed (stowed)
Max. drive speed (elevated)
Raise/lower time
Gradeability (engine)
Gradeability (batteries)
Max. stabilizer leveling (front to rear)
Max. stabilizer leveling (side to side)
Inside turning radius
Outside turning radius
Tires
Controls
Drive system
Power source
Weight
Max. working height (ANSI metric)
Max. platform height (ANSI metric)
Platform size (stowed) (ANSI metric)
Platform size (extended) (ANSI metric)
Deck extension length (ANSI metric)
Overall width (ANSI metric)
Overall length (ANSI metric)
Stowed Height (ANSI Metric)
Min. height (guardrails folded) (ANSI metric)
Ground clearance (ANSI metric)
Platform capacity (SWL - ANSI metric)
Max. drive height (ANSI metric)
Max. drive speed (stowed) (ANSI metric)
Max. drive speed (elevated) (ANSI metric)
Raise/lower time (ANSI Metric)
Gradeability (engine) (ANSI metric)
Gradeability (batteries) (ANSI metric)
Max. stabilizer leveling (front to rear) (ANSI metric)
Max. stabilizer leveling (side to side) (ANSI metric)
Inside turning radius (ANSI metric)
Outside turning radius (ANSI metric)
Tires (ANSI metric)
Controls (ANSI metric)
Drive system (ANSI metric)
Power source (ANSI Metric)
Weight (ANSI Metric)
Max. working height (CE Imperial)
Max. platform height (CE imperial)
Platform size (stowed) (CE imperial)
Platform size (extended) (CE imperial)
Deck extension length (CE imperial)
Overall width (CE imperial)
Overall length (CE imperial)
Stowed Height (CE Imperial)
Min. height (guardrails folded) (CE imperial)
Ground clearance (CE imperial)
Platform capacity (SWL - CE Imperial)
Max. drive height (CE imperial)
Max. drive speed (stowed) (CE imperial)
Max. drive speed (elevated) (CE imperial)
Raise/lower time (CE Imperial)
Gradeability (engine) (CE imperial)
Gradeability (batteries) (CE imperial)
Max. stabilizer leveling (front to rear) (CE imperial)
Max. stabilizer leveling (side to side) (CE imperial)
Inside turning radius (CE imperial)
Outside turning radius (CE imperial)
Tires (CE imperial)
Controls (CE imperial)
Drive system (CE imperial)
Power source (CE Imperial)
Weight (CE imperial)
Max. working height (CE metric)
Max. platform height (CE metric)
Platform size (stowed) (CE metric)
Platform size (extended) (CE metric)
Deck extension length (CE metric)
Overall width (CE metric)
Overall length (CE metric)
Stowed Height (CE Metric)
Min. height (guardrails folded) (CE metric)
Ground clearance (CE metric)
Max. drive height (CE metric)
Max. drive speed (stowed) (CE metric)
Max. drive speed (elevated) (CE metric)
Raise/lower time (CE Metric)
Gradeability (engine) (CE metric)
Gradeability (batteries) (CE metric)
Max. stabilizer leveling (front to rear) (CE metric)
Max. stabilizer leveling (side to side) (CE metric)
Inside turning radius (CE metric)
Outside turning radius (CE metric)
Tires (CE metric)
Controls (CE metric)
Drive system (CE metric)
Power source (CE Metric)
Weight (CE Metric)
Max. working height
33 ft
Max. platform height
27 ft
Stowed height
8 ft 6 in
Platform size (stowed)
9 ft 8 in x 5 ft 2 in
Platform size (extended)
13 ft 1 in x 5 ft 2 in
Deck extension length
4 ft
Min. height (guardrails folded)
6 ft
Ground clearance
13 in
Platform capacity (SWL)
1,250 lbs
Overall width
5 ft 10 in
Overall length
11 ft
Max. drive height
27 ft
Max. drive speed (elevated)
0.3 mph
Max. drive speed (stowed)
2.8 mph
Raise / lower time
26 / 30 sec
Inside turning radius
8 ft
Outside turning radius
15 ft 7 in
Tires
27 x 10.5 - 15 non-marking foam filled
Controls
Proportional joystick
Drive system
4 wheel drive
Power source
Kubota D-902 water cooled diesel 22.5 hp - Tier 4 Final & 4 x 6v 305 Ah batteries
Weight
6,834 lbs

Specifications subject to change without notice. The equipment hereunder have been subject to limited testing, and any performance specifications and representations are the result of limited testing. Photos and diagrams are shown for illustrative purposes only. Snorkel makes no warranty, representation, or guarantee regarding the information contained herein or the suitability of its equipment for any particular purpose. It is the Buyer’s responsibility to independently determine suitability of any equipment or parts, and to test and verify the same. Refer to appropriate Snorkel operator’s manual for detailed instructions on the proper use and maintenance.

Last Updated
01/2019

Standard Features

  • DC & diesel power - for indoor & outdoor work
  • 4 wheel drive
  • Roll-out deck extension
  • 4 hydraulic stabilizers with automatic leveling
  • Non-marking foam filled tires
  • Proportional controls
  • Power line to platform
  • Drive motion alarm
  • Descent alarm
  • Fold-down guardrails
  • Flashing amber light (x2)
  • Articulating axle
  • Hour meter & on-board diagnostics display
  • Manual lowering valve
  • Dual lanyard attachment points
  • 2 years parts & labor, 5 year structural warranty

Options

  • Special paint colors
  • Hydraulic generator 110V 2kW
  • Nylon spreader pads (set of 4)
  • Environmental hydraulic oil
  • Platform overload system
