S2255RTE Product Hero
27 ft 10 in Working Height
925 lbs Platform Capacity
5,313 lbs Weight

S2255RTE

The Snorkel S2255RTE is an electric narrow rough terrain scissor lift equipped with long-lasting lithium batteries. The quiet performance means it is suitable for indoor and outdoor use without sacrificing power. Its ultra-narrow width and low weight allows this scissor lift to be easily towed on a tandem trailer.

Specifications

Max. working height
27 ft 10 in
Max. platform height
21 ft 10 in
Platform size (stowed)
4 ft 7 in x 8 ft 9 in
Platform size (extended)
4 ft 7 in x 12 ft 8 in
Deck extension length
3 ft 11 in
Overall length
10 ft 10 in
Overall width
4 ft 9 in
Min. height (guardrails folded)
6 ft 6 in
Stowed height
7 ft 8 in
Ground clearance
10.2 in
Platform capacity (SWL)
925 lbs
Max. drive height
20 ft 4 in
Max. wind speed
28 mph
Max. drive speed (elevated)
0.4 mph
Max. drive speed (stowed)
3.2 mph
Raise / lower time
26/30 sec
Gradeability
35%
Max. outrigger levelling (front to rear)
Max. outrigger levelling (side to side)
10º
Inside turning radius
8 ft 2 in
Outside turning radius
15 ft 7 in
Exit/entry angle
20°
Tires
23” x 8.9” - 12 non-marking
Controls
proportional joystick
Drive system
4 wheel drive
Power source
222Ah Li-ion batteries with integrated BMS
Operating Temperature
(-)77°F to (+)140°F
Charger
High frequency smart on-board 50A battery charger
Motor
AC electric motor
Weight
5,313 lbs

Specifications subject to change without notice. The equipment hereunder have been subject to limited testing, and any performance specifications and representations are the result of limited testing. Photos and diagrams are shown for illustrative purposes only. Snorkel makes no warranty, representation, or guarantee regarding the information contained herein or the suitability of its equipment for any particular purpose. It is the Buyer’s responsibility to independently determine suitability of any equipment or parts, and to test and verify the same. Refer to appropriate Snorkel operator’s manual for detailed instructions on the proper use and maintenance.

Last Updated
06/2021

Standard Features

  • Two lithium-ion battery systems 222Ah
  • 4 wheel drive
  • 4 hydraulic stabilizers with automatic leveling
  • Roll-out deck extension
  • Proportional controls
  • Non-marking foam filled tires
  • Power line to platform
  • Drive motion alarm
  • Descent alarm
  • Oscillating axle
  • Manual lowering valve
  • Flashing amber light
  • Dual lanyard attachment points
  • Hour meter
  • 2000 charging cycles/2 year** lithium battery warranty
  • 2 year parts & labor, 5 year structural warranty

Options

  • Special paint colors
  • Additional 111Ah battery system
  • Nylon spreader pads (set of 4)
  • Environmental hydraulic oil
  • Snorkel OnSite™ telematics
