Proven Persistent Snorkel S2255BE
27 ft 10 in Working Height
925 lbs Platform Capacity
6,130 lbs Weight

S2255BE

The Snorkel S2255BE narrow rough terrain scissor lift delivers off-road performance anywhere. A bi-energy power system allows operators to switch between a diesel engine for outdoor work and zero emission battery power for indoor work. The dynamic S2255BE provides excellent versatility on the job, and is equipped with high grip non-marking tires as standard.

Specifications

Max. working height
27 ft 10 in
Max. platform height
21 ft 10 in
Platform size (stowed)
4 ft 7 in x 8 ft 11 in
Platform size (extended)
4 ft 7 in x 12 ft 10 in
Deck extension length
4 ft
Overall length
10 ft 10 in
Overall width
4 ft 9 in
Min. height (guardrails folded)
6 ft 6 in
Stowed height
7 ft 8 in
Ground clearance
10 in
Platform capacity (SWL)
925 lbs
Max. drive height
20 ft 4 in
Max. wind speed
28 mph
Max. drive speed (elevated)
0.4 mph
Max. drive speed (stowed)
3.2 mph
Raise / lower time
26 / 30 seconds
Gradeability (engine)
35%
Max. stabilizer leveling (front to rear)
Max. stabilizer leveling (side to side)
10º
Inside turning radius
8 ft 2 in
Outside turning radius
15 ft 7 in
Tires
23 in x 8.9 in - 12 non-marking
Controls
Proportional joystick
Drive system
4 wheel drive
Power source
Kubota diesel engine
Weight
6,130 lbs

Specifications subject to change without notice. The equipment hereunder have been subject to limited testing, and any performance specifications and representations are the result of limited testing. Photos and diagrams are shown for illustrative purposes only. Snorkel makes no warranty, representation, or guarantee regarding the information contained herein or the suitability of its equipment for any particular purpose. It is the Buyer’s responsibility to independently determine suitability of any equipment or parts, and to test and verify the same. Refer to appropriate Snorkel operator’s manual for detailed instructions on the proper use and maintenance.

Last Updated
03/2020

Standard Features

  • DC & diesel power for indoor and outdoor work
  • 4 wheel drive
  • 4 hydraulic stabilizers with automatic leveling
  • Roll out deck extension
  • Non-marking foam filled tires
  • Proportional controls
  • Power line to platform
  • Drive motion alarm
  • Descent alarm
  • Articulating axle
  • Manual lowering valve
  • Flashing amber light
  • Dual lanyard attachment points
  • Hour meter
  • 2 years parts & labor, 5 year structural warranty

Options

  • Special paint colors (one color)
  • Special paint colors (two color)
  • Nylon spreader pads (set of 4)
  • Environmental hydraulic oil
