Pushing Beyond Snorkel S3210P
15 ft 10 in Working Height
529 lbs Platform Capacity
1,036 lbs Weight

S3210P

The Snorkel S3210P push-around scissor lift is rated for outdoor low level work. It offers a durable design for tough site conditions with no stabilizers required. Ideal for low level working at height, this mini scissor lift easily passes through standard doorways.

Specifications

Max. working height
15 ft 10 in
Max. platform height
9 ft 10 in
Overall length
3 ft 11 in
Overall width
2 ft 8 in
Platform size (outside)
43 in x 20 in
Stowed height
5 ft 10 in
Platform capacity (SWL)
529 lbs
Max. wind speed
28 mph
Raise / lower time
19 / 26 seconds
Power source
12V DC battery
Charger
Built in multi-voltage (90V - 240V)
Weight
1,036 lbs

Specifications subject to change without notice. The equipment hereunder have been subject to limited testing, and any performance specifications and representations are the result of limited testing. Photos and diagrams are shown for illustrative purposes only. Snorkel makes no warranty, representation, or guarantee regarding the information contained herein or the suitability of its equipment for any particular purpose. It is the Buyer’s responsibility to independently determine suitability of any equipment or parts, and to test and verify the same. Refer to appropriate Snorkel operator’s manual for detailed instructions on the proper use and maintenance.

Last Updated
03/2020

Standard Features

  • Outdoor–rated
  • Auto brake system
  • Tilt sensor
  • Saloon-door style entry gates
  • Integrated battery charger 90V - 240V
  • Battery charge indicator
  • Forklift pockets
  • Emergency lowering system
  • Non-marking casters
  • Slide-out service trays
  • 2 year parts & labor, 5 year structural warranty

Options

  • Special paint colors
  • Environmental hydraulic oil
