S3008P
14 ft 2 in Working Height
500 lbs Platform Capacity
770 lbs Weight

S3008P

The Snorkel S3008P push-around mini scissor lift offers innovative low level working at height in indoor applications. Designed as a safer and more productive alternative to ladders and podiums, this mini scissor lift fits easily into tight areas and can be carried in a passenger elevator. Built with heavy-duty, all-steel components, and operated with simple push button controls, the S3008P is a reliable additional to a jobsite or rental fleet.

Specifications

Max. working height
Max. platform height
Platform capacity (SWL)
Overall width
Overall length
Stowed height
Max. wind speed
Raise/lower time
Power source
Charger
Weight
Max. working height (ANSI metric)
Max. platform height (ANSI metric)
Platform capacity (SWL - ANSI metric)
Overall width (ANSI metric)
Overall length (ANSI metric)
Stowed Height (ANSI Metric)
Max. wind speed (ANSI metric)
Raise/lower time (ANSI Metric)
Power source (ANSI Metric)
Charger (ANSI metric) -- NOTE: **Charger (CE metric) is out of alphabetical order - see next page
Weight (ANSI Metric)
Max. working height (CE Imperial)
Max. platform height (CE imperial)
Platform capacity (SWL - CE Imperial)
Overall width (CE imperial)
Overall length (CE imperial)
Stowed Height (CE Imperial)
Max. wind speed (CE imperial)
Raise/lower time (CE Imperial)
Power source (CE Imperial)
Charger (CE imperial)
Weight (CE imperial)
Max. working height (CE metric)
Max. platform height (CE metric)
Platform capacity (SWL - CE Metric)
Overall width (CE metric)
Overall length (CE metric)
Stowed Height (CE Metric)
Max. wind speed (CE metric)
Raise/lower time (CE Metric)
Power source (CE Metric)
**Charger (CE metric) (**out of alphabetical order)
Weight (CE Metric)
Max. working height
14 ft 2 in
Max. platform height
8 ft 2 in
Stowed height
5 ft 10 in
Platform capacity (SWL)
500 lbs
Overall width
2 ft 4 in
Overall length
3 ft 11 in
Max. wind speed
0 mph
Raise / lower time
13 / 17 sec
Power source
12V DC battery
Charger
Built in multi-voltage (90V - 240V)
Weight
770 lbs

Specifications subject to change without notice. The equipment hereunder have been subject to limited testing, and any performance specifications and representations are the result of limited testing. Photos and diagrams are shown for illustrative purposes only. Snorkel makes no warranty, representation, or guarantee regarding the information contained herein or the suitability of its equipment for any particular purpose. It is the Buyer’s responsibility to independently determine suitability of any equipment or parts, and to test and verify the same. Refer to appropriate Snorkel operator’s manual for detailed instructions on the proper use and maintenance.

Last Updated
01/2019

Standard Features

  • Auto brake system
  • Tilt sensor
  • Saloon-door style entry gates
  • Integrated battery charger 90V - 240V
  • Battery charge indicator
  • Forklift pockets
  • Emergency lowering system
  • Non-marking casters
  • Slide-out service trays
  • 2 year parts & labor, 5 year structural warranty

Options

  • Special paint colors
  • Environmental hydraulic oil

Downloads

Specification Sheet (ANSI Metric)

English Français

Specification Sheet (ANSI Imperial)

English

Product Range Multifold (ANSI)

English Español
