Reach New Heights Snorkel S4740E
45 ft 5 in Working Height
550 lbs Platform Capacity
6,825 lbs Weight

S4740E

The Snorkel S4740E is the only Snorkel electric scissor lift with available hydraulic and electric drive. Durable lead acid batteries provide long-lasting performance. The rugged and robust S4740E features a variable tilt system suitable for indoor and outdoor use.

Specifications

Max. working height
45 ft 5 in
Max. platform height
39 ft 5 in
Platform size (stowed)
43 in x 84 in
Platform size (extended)
43 in x 132 in
Deck extension length
48 in
Overall length (with step)
90.6 in
Overall length (without step)
89 in
Overall width
47 in
Min. height (guardrails folded)
76 in
Stowed height
101 in
Ground clearance (stowed)
2.63 in
Ground clearance (elevated)
.75 in
Platform capacity (SWL)
550 lbs
Max. drive height
39 ft 5 in
Max. wind speed
28 mph
Max. drive speed (elevated)
0.4 mph
Max. drive speed (stowed)
2.0 mph
Raise / lower time
68 / 72 seconds
Gradeability
25%
Inside turning radius
21 in
Outside turning radius
95 in
Tires
15 in x 5 in non-marking rubber
Controls
Proportional
Drive system
2 wheel drive
Power source
24V DC battery electric
Charger
90 - 240V, 25 amp
Weight
6,825 lbs

Specifications subject to change without notice. The equipment hereunder have been subject to limited testing, and any performance specifications and representations are the result of limited testing. Photos and diagrams are shown for illustrative purposes only. Snorkel makes no warranty, representation, or guarantee regarding the information contained herein or the suitability of its equipment for any particular purpose. It is the Buyer’s responsibility to independently determine suitability of any equipment or parts, and to test and verify the same. Refer to appropriate Snorkel operator’s manual for detailed instructions on the proper use and maintenance.

Last Updated
04/2020

Standard Features

  • Hydraulic drive
  • Roll-out deck extension with dual locks
  • Non-marking tires
  • Swing-out service trays
  • Saloon-door style entry gates
  • Descent alarm
  • All motion alarm
  • 2 persons indoors
  • 1 person outdoors
  • Proportional controls, including descent
  • Power line to platform
  • Loading pendant
  • Hour meter & on-board diagnostics display
  • Integrated battery charger
  • Battery condition indicator
  • Crane & forklift points
  • Dual lanyard attachment points
  • Scissor stack roller slide plates (set of 2)
  • 2 year parts & labor, 5 year structural warranty

Options

  • Special paint colors
  • Electric drive
  • Flashing amber light
  • Airline to platform
  • Aircraft bumpguard package
  • 110V AC 800W inverter
  • Environmental hydraulic oil
