S4726E
32 ft Working Height
1,000 lbs Platform Capacity
4,750 lbs Weight

S4726E

The Snorkel S4726E electric scissor lift is designed to handle the heavy loads. With a high lift capacity and spacious platform featuring roll-out extension deck, the S4726E can handle most applications. Constructed from heavy-duty steel, and designed for a long working life, the S4726E delivers a low total cost of ownership.

Specifications

Max. working height
32 ft
Max. platform height
26 ft
Platform size (stowed)
43 in x 84.38 in
Platform size (extended)
43 in x 132.38 in
Deck extension length
48 in
Overall length (with step)
90.6 in
Overall length (without step)
89 in
Overall width
47 in
Min. height (guardrails folded)
73 in
Stowed height
90.2 in
Ground clearance (stowed)
2.63 in
Ground clearance (elevated)
.75 in
Platform capacity (SWL)
1,000 lbs
Max. drive height
26 ft
Max. wind speed
28 mph
Max. drive speed (elevated)
0.4 mph
Max. drive speed (stowed)
2.0 mph
Raise / lower time
50 / 58 sec
Gradeability
25%
Inside turning radius
21 in
Outside turning radius
95 in
Tires
15 in x 5 in non-marking rubber
Controls
Proportional
Drive system
2 wheel drive
Power source
24V DC battery electric
Charger
90 - 240V, 25 amp
Weight
4,750 lbs

Specifications subject to change without notice. The equipment hereunder have been subject to limited testing, and any performance specifications and representations are the result of limited testing. Photos and diagrams are shown for illustrative purposes only. Snorkel makes no warranty, representation, or guarantee regarding the information contained herein or the suitability of its equipment for any particular purpose. It is the Buyer’s responsibility to independently determine suitability of any equipment or parts, and to test and verify the same. Refer to appropriate Snorkel operator’s manual for detailed instructions on the proper use and maintenance.

Last Updated
01/2019

Standard Features

  • Roll-out deck extension with dual locks
  • Non-marking tires
  • Swing-out service trays
  • Saloon-door style entry gates
  • Descent alarm
  • All motion alarm
  • Proportional controls, including descent
  • Key switch
  • 2 persons indoors
  • 1 person outdoors
  • Loading pendant
  • Power line to platform
  • Hour meter & on-board diagnostic display
  • Integrated battery charger
  • Battery condition indicator
  • Crane & forklift points
  • Dual lanyard attachment points
  • Scissor stack roller slide plates (set of 2)
  • 2 year parts & labor, 5 year structural warranty

Options

  • Special paint colors
  • Flashing amber light
  • 110V AC 800W inverter
  • Airline to platform
  • Aircraft bumpguard package
  • Panel carrier
  • Environmental hydraulic oil
  • Snorkel Guard™ secondary guarding system
  • Platform overload system
