S3010E
15 ft 11 in Working Height
500 lbs Platform Capacity
1,091 lbs Weight

S3010E

The Snorkel S3010E is a self-propelled electric scissor lift designed small yet mighty. Its compact dimensions and zero inside turning radius are ideal for working in tight spaces, and ‘point and go’ joystick controls make it super-easy to operate. The S3010E can be driven at full height and carried in passenger elevators for complete versatility.

Specifications

Max. working height
Max. platform height
Platform size
Overall length
Overall width
Stowed height
Ground clearance
Platform capacity (SWL)
Max. wind speed
Max. drive height
Max. drive speed (elevated)
Max. drive speed (stowed)
Raise/lower time
Gradeability
Max. operating slope
Inside turning radius
Outside turning radius
Tires
Controls
Parking brake
Drive system
Power source
Charger
Weight
Max. working height (ANSI metric)
Max. platform height (ANSI metric)
Platform size (ANSI metric)
Overall length (ANSI metric)
Overall width (ANSI metric)
Stowed Height (ANSI Metric)
Ground clearance (ANSI metric)
Platform capacity (SWL - ANSI metric)
Max. wind speed (ANSI metric)
Max. drive height (ANSI metric)
Max. drive speed (stowed) (ANSI metric)
Max. drive speed (elevated) (ANSI metric)
Raise/lower time (ANSI Metric)
Gradeability (ANSI metric)
Max. operating slope (ANSI metric)
Inside turning radius (ANSI metric)
Outside turning radius (ANSI metric)
Tires (ANSI metric)
Parking brake (ANSI metric)
Drive system (ANSI metric)
Controls (ANSI metric)
Power source (ANSI Metric)
Charger (ANSI metric) -- NOTE: **Charger (CE metric) is out of alphabetical order - see next page
Weight (ANSI Metric)
Max. working height (CE Imperial)
Max. platform height (CE imperial)
Platform size (CE imperial)
Overall length (CE imperial)
Overall width (CE imperial)
Stowed Height (CE Imperial)
Ground clearance (CE imperial)
Platform capacity (SWL - CE Imperial)
Max. wind speed (CE imperial)
Max. drive height (CE imperial)
Max. drive speed (stowed) (CE imperial)
Max. drive speed (elevated) (CE imperial)
Raise/lower time (CE Imperial)
Gradeability (CE imperial)
Max. operating slope (CE imperial)
Inside turning radius (CE imperial)
Outside turning radius (CE imperial)
Tires (CE imperial)
Drive system (CE imperial)
Controls (CE imperial)
Power source (CE Imperial)
Charger (CE imperial)
Parking brake (CE imperial)
Weight (CE imperial)
Max. working height (CE metric)
Max. platform height (CE metric)
Platform size (CE metric)
Overall length (CE metric)
Overall width (CE metric)
Stowed Height (CE Metric)
Ground clearance (CE metric)
Platform capacity (SWL - CE Metric)
Max. wind speed (CE metric)
Max. drive height (CE metric)
Max. drive speed (stowed) (CE metric)
Max. drive speed (elevated) (CE metric)
Raise/lower time (CE Metric)
Gradeability (CE metric)
Max. operating slope (CE metric)
Inside turning radius (CE metric)
Outside turning radius (CE metric)
Tires (CE metric)
Parking brake (CE metric)
Drive system (CE metric)
Controls (CE metric)
Power source (CE Metric)
**Charger (CE metric) (**out of alphabetical order)
Weight (CE Metric)
Max. working height
15 ft 11 in
Max. platform height
9 ft 11 in
Platform size
43 in x 20 in
Stowed height
5 ft 11 in
Ground clearance
2.3 in
Platform capacity (SWL)
500 lbs
Overall width
30.3 in
Overall length
49.6 in
Max. wind speed
0 mph
Max. drive height
9 ft 11 in
Max. drive speed (elevated)
0.4 mph
Max. drive speed (stowed)
2.2 mph
Raise / lower time
18 / 25 sec
Gradeability
25%
Max. operating slope
Inside turning radius
0 in
Outside turning radius
4 ft 9 in
Tires
9 in non-marking rubber
Controls
2-axis proportional joystick
Parking brake
2 wheel automatic
Drive system
DC direct drive
Power source
2 x 12V 105Ah
Charger
100-240V 50/60Hz Auto, 30 amp
Weight
1,091 lbs

Specifications subject to change without notice. The equipment hereunder have been subject to limited testing, and any performance specifications and representations are the result of limited testing. Photos and diagrams are shown for illustrative purposes only. Snorkel makes no warranty, representation, or guarantee regarding the information contained herein or the suitability of its equipment for any particular purpose. It is the Buyer’s responsibility to independently determine suitability of any equipment or parts, and to test and verify the same. Refer to appropriate Snorkel operator’s manual for detailed instructions on the proper use and maintenance.

Last Updated
01/2019

Standard Features

  • Highly maneuverable skid steer
  • Zero inside turning radius
  • Saloon-door style entry gates
  • 1 person indoors
  • Non-marking tires
  • Proportional point & go joystick controls
  • Integrated battery charger
  • Battery condition indicator
  • Crane points & through-the-chassis fork pockets
  • Selectable motion alarm
  • Tilt & descent alarm
  • Hour meter
  • Horn
  • 2 year parts & labor, 5 year structural warranty

Options

  • Special paint colors
  • Environmental hydraulic oil
