Powerfully Productive - Snorkel ML20M
19 ft 8 in Lift Height (Forks Up)
600 lbs Max. Load Capacity (14 in. load center)
332 lbs Weight

ML20M

The Snorkel ML20M mini material lift raises standards in material lifting. Ideal for industrial and warehouse applications, a dual handle, shift-on-the-fly, two-speed winch quickly raises loads to increase productivity. A reduced height mast is designed to pass through a single doorway without tilting back. This lift is also built with durable aluminum for a long working life.

Specifications

Lift height (forks up)
Lift height (forks down)
Stowed width
Stabilizer width
Stowed length
Operating length
Stowed height
Fork width (outside)
Fork length
Ground clearance
Max. load capacity (14 in. load center)
Max. load capacity (24 in. load center)
Max. load capacity (42. In load center)
Min. load height
Winch (high speed)
Winch (low speed)
Weight
Lift height (forks up) (ANSI metric)
Lift height (forks down) (ANSI metric)
Stowed width (ANSI metric)
Stabilizer width (ANSI metric)
Stowed length (ANSI metric)
Operating length (ANSI metric)
Stowed Height (ANSI Metric)
Fork width (outside) (ANSI metric)
Fork length (ANSI metric)
Ground clearance (ANSI metric)
Max. load capacity (14 in. load center) (ANSI metric)
Max. load capacity (24 in. load center) (ANSI metric)
Max. load capacity (42. In load center) (ANSI metric)
Min. load height (ANSI metric)
Winch (high speed) (ANSI metric)
Winch (low speed) (ANSI metric)
Weight (ANSI Metric)
Lift height (forks up) (CE imperial)
Lift height (forks down) (CE imperial)
Stowed width (CE imperial)
Stabilizer width (CE imperial)
Stowed length (CE imperial)
Operating length (CE imperial)
Stowed Height (CE Imperial)
Fork width (outside) (CE imperial)
Fork length (CE imperial)
Ground clearance (CE imperial)
Max. load capacity (14 in. load center) (CE imperial)
Max. load capacity (24 in. load center) (CE imperial)
Max. load capacity (42. In load center) (CE imperial)
Min. load height (CE imperial)
Winch (high speed) (CE imperial)
Winch (low speed) (CE imperial)
Weight (CE imperial)
Lift height (forks up) (CE metric)
Lift height (forks down) (CE metric)
Stowed width (CE metric)
Stabilizer width (CE metric)
Stowed length (CE metric)
Operating length (CE metric)
Stowed Height (CE Metric)
Fork width (outside) (CE metric)
Fork length (CE metric)
Ground clearance (CE metric)
Max. load capacity (14 in. load center) (CE metric)
Max. load capacity (24 in. load center) (CE metric)
Max. load capacity (42. In load center) (CE metric)
Min. load height (CE metric)
Winch (high speed) (CE metric)
Winch (low speed) (CE metric)
Weight (CE Metric)
Lift height (forks up)
19 ft 8 in
Lift height (forks down)
17 ft 11 in
Stowed width
30.5 in
Stabilizer width
64 in
Stowed length
36 in
Operating length
6 ft 11 in
Stowed height
5 ft 3 in
Fork width (outside)
23 in
Fork length
30 in
Ground clearance
2.5 in
Max. load capacity (14 in. load center)
600 lbs
Max. load capacity (24 in. load center)
400 lbs
Max. load capacity (42 in. load center)
200 lbs
Min. load height
6 in
Winch (high speed)
4 cranks/ft
Winch (low speed)
15 cranks/ft
Weight
332 lbs

Specifications subject to change without notice. The equipment hereunder have been subject to limited testing, and any performance specifications and representations are the result of limited testing. Photos and diagrams are shown for illustrative purposes only. Snorkel makes no warranty, representation, or guarantee regarding the information contained herein or the suitability of its equipment for any particular purpose. It is the Buyer’s responsibility to independently determine suitability of any equipment or parts, and to test and verify the same. Refer to appropriate Snorkel operator’s manual for detailed instructions on the proper use and maintenance.

Last Updated
02/2019

Standard Features

  • Stabilizers with non-marking swivel casters (ML12M)
  • Non-marking transport/loading wheels
  • Dual handle, two-speed shift-on-the-fly winch
  • Metal cable pulleys with sealed bearings
  • Heavy-gage aluminum extrusions
  • Heavy duty non-marking casters
  • Quick-fold stabilizers
  • Crane attachment point
  • Cable guard
  • Smart latch system
  • Mast brake
  • 2 year parts & labor, 5 year structural warranty

Options

  • Special paint colors
  • Adjustable forks
  • Fork extensions
  • Boom
  • Pipe cradle
  • Load platform
  • Stabilizers with non-marking swivel casters
