11 ft Lift Height (Forks Up)
900 lbs Max. Load Capacity (14 in. load center)
234 lbs Weight

ML10I

The ML10I industrial material lift is built for handle the work. Designed narrow to maneuver through standard doorways without tilting back, this material lift is also robust for heavy-duty applications. For improved productivity, it is equipped with a dual handle, shift-on-the-fly, two-speed winch.

Specifications

Lift height (forks up)
11 ft
Lift height (forks down)
9 ft 4 in
Stowed width
30.5 in
Stabilizer width
5 ft 4 in
Stowed length
2 ft 9 in
Operating length
5 ft 2 in
Fork width (outside)
23 in
Fork length
30 in
Stowed height
6 ft 3 in
Ground clearance
2.5 in
Max. load capacity (14 in. load center)
900 lbs
Max. load capacity (24 in. load center)
750 lbs
Max. load capacity (42 in. load center)
350 lbs
Min. load height
6 in
Winch (high speed)
4 cranks/ft
Winch (low speed)
15 cranks/ft
Weight
234 lbs

Specifications subject to change without notice. The equipment hereunder have been subject to limited testing, and any performance specifications and representations are the result of limited testing. Photos and diagrams are shown for illustrative purposes only. Snorkel makes no warranty, representation, or guarantee regarding the information contained herein or the suitability of its equipment for any particular purpose. It is the Buyer’s responsibility to independently determine suitability of any equipment or parts, and to test and verify the same. Refer to appropriate Snorkel operator’s manual for detailed instructions on the proper use and maintenance.

Last Updated
03/2020

Standard Features

  • Non-marking transport/loading wheels
  • Dual handle, two-speed shift-on-the-fly winch
  • Metal cable pulleys with sealed bearings
  • Heavy-gauge aluminium extrusions
  • Heavy-duty, non-marking casters
  • Crane attachment point
  • Cable guard
  • Mast brake
  • 2 year parts & labour, 5 year structural warranty

Options

  • Special paint colours (one colour)
  • Adjustable forks
  • Fork extensions
  • Boom
  • Pipe cradle
  • Load platform
  • Stabilizers with non-marking swivel casters
  • Straddle base
