TM16E
22 ft Working Height
500 lbs Platform Capacity
2,430 lbs Weight

TM16E

The Snorkel TM16E delivers the tallest working height in Snorkel’s line of self-propelled telescopic mast lifts. Featuring an electric drive system, this mast lift offers longer duty cycles on the job. Smooth proportional controls allows for precise positioning where needed most.

Specifications

Max. working height
22 ft
Max. platform height
16 ft
Platform size (stowed)
27 in x 39 in
Platform size (extended)
27 in x 59 in
Deck extension length
20 in
Overall length
4 ft 6 in
Overall width
2 ft 6 in
Stowed height
6 ft 6 in
Ground clearance
3 in
Platform capacity (SWL)
500 lbs
Max. drive height
16 ft
Max. wind speed
0 mph
Max. drive speed (elevated)
0.4 mph
Max. drive speed (stowed)
2.5 mph
Raise / lower time
12.5 / 10.5 sec
Gradeability
25%
Max. operating slope (side to side)
1.5°
Max. operating slope (front to back)
1.5º
Inside turning radius
0 in
Outside turning radius
55.5 in
Tires
12.7 in non-marking rubber
Controls
Proportional
Parking brake
2 wheel, spring-applied, electric release
Drive system
Dual DC motors
Power source
24V 220Ah batteries
Battery charger
20 amp
Weight
2,430 lbs

Specifications subject to change without notice. The equipment hereunder have been subject to limited testing, and any performance specifications and representations are the result of limited testing. Photos and diagrams are shown for illustrative purposes only. Snorkel makes no warranty, representation, or guarantee regarding the information contained herein or the suitability of its equipment for any particular purpose. It is the Buyer’s responsibility to independently determine suitability of any equipment or parts, and to test and verify the same. Refer to appropriate Snorkel operator’s manual for detailed instructions on the proper use and maintenance.

Last Updated
02/2019

Standard Features

  • Roll-out deck extension
  • Proportional controls
  • Saloon-door style entry gates
  • Descent & tilt alarms
  • Emergency lowering at chassis controls
  • Non-marking rubber tires
  • 2 persons indoors
  • 1 person outdoors (TM12E only)
  • Crane lift points
  • Hour meter & on-board diagnostics display
  • Horn
  • Selectable motion alarm
  • Integrated battery charger 110V 20A
  • 2 year parts & labor, 5 year structural warranty

Options

  • Special paint colors
  • Environmental hydraulic oil
  • Order picker tray
  • CSA compliant
