TM12E
18 ft Working Height
500 lbs Platform Capacity
1,850 lbs Weight

TM12E

The Snorkel TM12E is an efficient self-propelled telescopic mast lift. This mast lift is compact in dimension and robust in performance with a smooth and quiet electric drive. A zero inside turning radius makes the TM12E easy to use in tight areas.

Specifications

Max. working height
Max. platform height
Platform size (stowed)
Platform size (extended)
Deck extension length
Overall length
Overall width
Stowed height
Ground clearance
Platform capacity (SWL)
Max. drive height
Max. wind speed
Max. drive speed (stowed)
Max. drive speed (elevated)
Raise/lower time
Gradeability
Max. operating slope (side to side)
Max. operating slope (front to back)
Inside turning radius
Outside turning radius
Tires
Parking brake
Drive system
Controls
Power source
Battery charger
Weight
Platform size (stowed) (ANSI metric)
Platform size (extended) (ANSI metric)
Deck extension length (ANSI metric)
Overall length (ANSI metric)
Overall width (ANSI metric)
Stowed Height (ANSI Metric)
Ground clearance (ANSI metric)
Platform capacity (SWL - ANSI metric)
Max. drive height (ANSI metric)
Max. wind speed (ANSI metric)
Max. drive speed (stowed) (ANSI metric)
Max. drive speed (elevated) (ANSI metric)
Raise/lower time (ANSI Metric)
Gradeability (ANSI metric)
Max. operating slope (side to side) (ANSI metric)
Max. operating slope (front to back) (ANSI metric)
Inside turning radius (ANSI metric)
Outside turning radius (ANSI metric)
Tires (ANSI metric)
Parking brake (ANSI metric)
Drive system (ANSI metric)
Controls (ANSI metric)
Power source (ANSI Metric)
Battery charger (ANSI metric)
Weight (ANSI Metric)
Max. working height (CE Imperial)
Max. platform height (CE imperial)
Platform size (stowed) (CE imperial)
Platform size (extended) (CE imperial)
Deck extension length (CE imperial)
Overall length (CE imperial)
Overall width (CE imperial)
Stowed Height (CE Imperial)
Ground clearance (CE imperial)
Platform capacity (SWL - CE Imperial)
Max. drive height (CE imperial)
Max. wind speed (CE imperial)
Max. drive speed (stowed) (CE imperial)
Max. drive speed (elevated) (CE imperial)
Raise/lower time (CE Imperial)
Gradeability (CE imperial)
Max. operating slope (side to side) (CE imperial)
Max. operating slope (front to back) (CE imperial)
Inside turning radius (CE imperial)
Outside turning radius (CE imperial)
Tires (CE imperial)
Parking brake (CE imperial)
Drive system (CE imperial)
Controls (CE imperial)
Power source (CE Imperial)
Battery charger (CE imperial)
Weight (CE imperial)
Max. working height (CE metric)
Max. platform height (CE metric)
Platform size (stowed) (CE metric)
Platform size (extended) (CE metric)
Deck extension length (CE metric)
Overall length (CE metric)
Overall width (CE metric)
Stowed Height (CE Metric)
Ground clearance (CE metric)
Platform capacity (SWL - CE Metric)
Max. drive height (CE metric)
Max. wind speed (CE metric)
Max. drive speed (stowed) (CE metric)
Max. drive speed (elevated) (CE metric)
Raise/lower time (CE Metric)
Max. operating slope (side to side) (CE metric)
Max. operating slope (front to back) (CE metric)
Inside turning radius (CE metric)
Outside turning radius (CE metric)
Tires (CE metric)
Parking brake (CE metric)
Drive system (CE metric)
Controls (CE metric)
Power source (CE Metric)
Battery charger (CE metric)
Weight (CE Metric)
Max. working height
18 ft
Max. platform height
12 ft
Stowed height
5 ft 6 in
Platform size (stowed)
29 in x 38 in
Platform size (extended)
29 in x 56 in
Deck extension length
20 in
Ground clearance
3 in
Platform capacity (SWL)
500 lbs
Overall width
2 ft 6 in
Overall length
4 ft 6 in
Max. wind speed
28 mph
Max. drive height
12 ft
Max. drive speed (elevated)
0.4 mph
Max. drive speed (stowed)
2.5 mph
Raise / lower time
12.5 / 10.5 sec
Gradeability
25%
Max. operating slope (side to side)
Max. operating slope (front to back)
Inside turning radius
0 in
Outside turning radius
55.5 in
Tires
12.7 in non-marking rubber
Controls
Proportional
Parking brake
2 wheel, spring-applied, electric release
Drive system
Dual DC motors
Power source
24V 220Ah batteries
Battery charger
20 amp
Weight
1,850 lbs

Specifications subject to change without notice. The equipment hereunder have been subject to limited testing, and any performance specifications and representations are the result of limited testing. Photos and diagrams are shown for illustrative purposes only. Snorkel makes no warranty, representation, or guarantee regarding the information contained herein or the suitability of its equipment for any particular purpose. It is the Buyer’s responsibility to independently determine suitability of any equipment or parts, and to test and verify the same. Refer to appropriate Snorkel operator’s manual for detailed instructions on the proper use and maintenance.

Last Updated
02/2019

Standard Features

  • Roll-out deck extension
  • Proportional controls
  • Saloon-door style entry gates
  • Descent & tilt alarms
  • Emergency lowering at chassis controls
  • Non-marking rubber tires
  • 2 persons indoors
  • 1 person outdoors (TM12E only)
  • Crane lift points
  • Hour meter & on-board diagnostics display
  • Horn
  • Selectable motion alarm
  • Integrated battery charger 110V 20A
  • 2 year parts & labor, 5 year structural warranty

Options

  • Special paint colors
  • Environmental hydraulic oil
  • Order picker tray
  • CSA compliant
