Designed to Deliver - Snorkel E-Z12 E-Z Loader 12,000lb delivery truck bed capacity
12,000 lbs Bed Capacity
5,000 lbs Tow Capacity

E-Z12

The Snorkel E-Z12 E-Z Loader delivery truck bed makes easy work of heavy loads. Designed to be efficient, the rapid ramp deployment allows for faster loading and unloading. Delivering a generous bed capacity, the E-Z12 is an efficient solution for heavy haulage.

NOTE: Customer to provide chassis. Capacity rating for bed only, vehicle capacity rating dependent on final configuration of chassis, options installed, road regulations, and drivetrain specifications.

Specifications

Bed capacity
12,000 lbs
Dove tail lift capacity
8,000 lbs
Tow capacity
5,000 lbs
Approximate G.V.W.
26,000 lbs
Hydraulic P.T.O.
14 gallons
Overall bed (w x l)
8 ft 6 in x 21 ft 3 in
Main bed (w x l)
8 ft 6 in x 13 ft 5 in
Dove tail (w x l)
8 ft 6 in x 7 ft 5 in
Flip tail (w x l)
8 ft 6 in x 4 ft 7 in
Bulk head height
5 ft
Cab to axle length
11 ft 6 in
Ramp length
11 ft 11 in
Bed height
3 ft 5 in
Max. dock height
5 ft 5 in
Ramp ° / %
18° / 32%
Hitch receiver tube
2 in
Wood Thickness
1 in
Min. chassis frame rail height
38 in

Specifications subject to change without notice. The equipment hereunder have been subject to limited testing, and any performance specifications and representations are the result of limited testing. Photos and diagrams are shown for illustrative purposes only. Snorkel makes no warranty, representation, or guarantee regarding the information contained herein or the suitability of its equipment for any particular purpose. It is the Buyer’s responsibility to independently determine suitability of any equipment or parts, and to test and verify the same. Refer to appropriate Snorkel operator’s manual for detailed instructions on the proper use and maintenance.

Last Updated
06/2021

Standard Features

  • Bulkhead bolted to the frame
  • Traction plate full ramp
  • Knife edge ramp
  • Chain tie-down points (every 1 ́ 2 ̋ to 1 ́ 10 ̋)
  • Dock loading ability
  • Nylon strap tie-down points
  • Positive tail lock (non-hydraulic)
  • 1 year all components, 3 year structural warranty (bed only)

*Customer supplies chassis.

Options

  • Special paint colors
  • 4ft tool box (recommended for EZ12/EZ24)
  • 5 ft tool box (recommended for EZ18)
  • 6 ft tool box (recommended for EZ12/EZ18/EZ24)
  • 8 ft tool box (recommended for EZ24)
  • 5 ft emergency light bar
  • LED loading work lights (each)
  • 10,000 lbs hydraullic winch with level winder (150 lbs)
  • 15,000 lbs hydraullic winch with level winder (200 lbs)
  • 2-way ‘winch only’ operation - 50’ corded pendant
  • 2-way ‘winch only’ operation - wireless radio remote
  • 6-way ‘winch + bed’ operation - wireless radio remote
  • 6-way ‘winch + bed’ operation (corded pendant)
  • PTO electric
  • PTO pump
  • PTO airshift
  • Chrome lug nut covers
  • Chrome hub caps
  • 1/4” aluminum diamond plate bulk head cover
