Truly Towable - Snorkel TL37J
41 ft 9 in Working Height
475 lbs Platform Capacity
3,498 lbs Weight

TL37J

The Snorkel TL37J is a high specification trailer-mounted boom lift. This highly maneuverable towable lift has fully proportional hydraulics and up-and-over access. Powered platform rotation and auto-leveling outriggers come as standard. This articulating boom also offers a bi-energy option for clean and quiet indoor use.

Specifications

Max. working height
Max. platform height
Max. horizontal reach
Platform width
Platform depth
Stabilizer footprint
Towing length
Towing width
Stowed height
Platform capacity (SWL)
Max. wind speed
Jib length
Jib arc
Platform rotation
Superstructure rotation (non-continuous)
Wheels
Controls
Power source
Battery
Power options
Weight
Max. working height (ANSI metric)
Max. platform height (ANSI metric)
Max. horizontal reach (ANSI metric)
Platform width (ANSI metric)
Platform depth (ANSI metric)
Stabilizer footprint (ANSI metric)
Towing length (ANSI metric)
Towing width (ANSI metric)
Stowed Height (ANSI Metric)
Platform capacity (SWL - ANSI metric)
Max. wind speed (ANSI metric)
Jib length (ANSI metric)
Jib arc (ANSI metric)
Platform rotation (ANSI metric)
Superstructure rotation (non-continuous) (ANSI metric)
Controls (ANSI metric)
Power source (ANSI Metric)
Battery (ANSI metric)
Power options (ANSI metric)
Weight (ANSI Metric)
Max. working height (CE Imperial)
Max. platform height (CE imperial)
Max. horizontal reach (CE imperial)
Platform width (CE imperial)
Platform depth (CE imperial)
Stabilizer footprint (CE imperial)
Towing length (CE imperial)
Towing width (CE imperial)
Stowed Height (CE Imperial)
Platform capacity (SWL - CE Imperial)
Max. wind speed (CE imperial)
Jib length (CE imperial)
Jib arc (CE imperial)
Platform rotation (CE imperial)
Power options (CE imperial)
Weight (CE imperial)
Max. working height (CE metric)
Max. platform height (CE metric)
Platform depth (CE metric)
Stabilizer footprint (CE metric)
Towing length (CE metric)
Towing width (CE metric)
Stowed Height (CE Metric)
Platform capacity (SWL - CE Metric)
Max. wind speed (CE metric)
Jib length (CE metric)
Jib arc (CE metric)
Platform rotation (CE metric)
Superstructure rotation (non-continuous) (CE metric)
Controls (CE metric)
Power source (CE Metric)
Battery (CE metric)
Power options (CE metric)
Weight (CE Metric)
Max. working height
41 ft 9 in
Max. platform height
35 ft 9 in
Max. horizontal reach
18 ft 5 in
Platform width
3 ft 9 in
Platform depth
2 ft 4 in
Stabilizer footprint
12 ft 9 in x 10 ft 10 in
Towing length
20 ft 11 in
Towing width
5 ft 3 in
Stowed height
6 ft 11 in
Platform capacity (SWL)
475 lbs
Max. wind speed
28 mph
Jib length
4 ft 3 in
Jib arc
130°
Platform rotation
160°
Superstructure rotation (non-continuous)
640°
Wheels
165/80 R13
Controls
Hydraulic proportional
Power source
24V DC battery
Power options
Gasoline; bi-energy (combustion & battery); AC electric
Battery
4 x 6V 225Ah
Weight
3,498 lbs

Specifications subject to change without notice. The equipment hereunder have been subject to limited testing, and any performance specifications and representations are the result of limited testing. Photos and diagrams are shown for illustrative purposes only. Snorkel makes no warranty, representation, or guarantee regarding the information contained herein or the suitability of its equipment for any particular purpose. It is the Buyer’s responsibility to independently determine suitability of any equipment or parts, and to test and verify the same. Refer to appropriate Snorkel operator’s manual for detailed instructions on the proper use and maintenance.

Last Updated
02/2019

Standard Features

  • 4ft 3in, 130° jib
  • In-line boom design for maximum rigidity
  • Hydraulic stabilizers
  • Hand pump emergency lowering from platform
  • Lock valves on all hydraulic cylinders
  • Proportional live hydraulic controls
  • Power line to platform
  • 2 year parts & labor, 5 year structural warranty

Options

  • Special paint colors
  • Work lights in platform
  • Flashing amber light
  • Nylon spreader pads (set of 4)
  • 110V/220V AC power
  • Gasoline power
  • Bi-energy (gas + batteries)
  • Environmental hydraulic oil
  • CSA compliant
