TB80
86 ft Working Height
500 lbs Platform Capacity
36,332 lbs Weight

TB80

The Snorkel TB80 telescopic boom lift reaches high on rough terrain. A powerful 4-wheel drive and superb ground clearance are well-suited for construction applications. Narrow dimensions and proportional controls make the TB80 easy to navigate throughout tough jobsites.

Specifications

Max. working height
Max. platform height
Max. horizontal reach
Platform size
Overall width
Overall length
Ground clearance
Platform capacity (SWL)
Max. drive height
Max. wind speed
Max. drive speed (stowed)
Max. drive speed (elevated)
Jib length
Jib arc
Platform rotation
Superstructure rotation
Tailswing
Raise/lower time
Gradeability
Inside turning radius
Outside turning radius
Tires
Controls
Drive system
Power source
Weight
Max. working height (ANSI metric)
Max. platform height (ANSI metric)
Max. horizontal reach (ANSI metric)
Platform size (ANSI metric)
Overall width (ANSI metric)
Overall length (ANSI metric)
Stowed Height (ANSI Metric)
Ground clearance (ANSI metric)
Platform capacity (SWL - ANSI metric)
Max. wind speed (ANSI metric)
Max. drive height (ANSI metric)
Max. drive speed (stowed) (ANSI metric)
Max. drive speed (elevated) (ANSI metric)
Platform rotation (ANSI metric)
Superstructure rotation (ANSI metric)
Tailswing (ANSI metric)
Raise/lower time (ANSI Metric)
Gradeability (ANSI metric)
Inside turning radius (ANSI metric)
Outside turning radius (ANSI metric)
Tires (ANSI metric)
Controls (ANSI metric)
Drive system (ANSI metric)
Power source (ANSI Metric)
Weight (ANSI Metric)
Max. working height (CE Imperial)
Max. platform height (CE imperial)
Max. horizontal reach (CE imperial)
Platform size (CE imperial)
Overall width (CE imperial)
Overall length (CE imperial)
Stowed Height (CE Imperial)
Ground clearance (CE imperial)
Platform capacity (SWL - CE Imperial)
Max. wind speed (CE imperial)
Max. drive height (CE imperial)
Max. drive speed (stowed) (CE imperial)
Max. drive speed (elevated) (CE imperial)
Platform rotation (CE imperial)
Superstructure rotation (CE imperial)
Tailswing (CE imperial)
Raise/lower time (CE Imperial)
Gradeability (CE imperial)
Inside turning radius (CE imperial)
Outside turning radius (CE imperial)
Tires (CE imperial)
Controls (CE imperial)
Drive system (CE imperial)
Power source (CE Imperial)
Weight (CE imperial)
Max. platform height (CE metric)
Max. working height (CE metric)
Platform size (CE metric)
Overall width (CE metric)
Overall length (CE metric)
Stowed Height (CE Metric)
Ground clearance (CE metric)
Platform capacity (SWL - CE Metric)
Max. wind speed (CE metric)
Max. drive height (CE metric)
Max. drive speed (stowed) (CE metric)
Max. drive speed (elevated) (CE metric)
Platform rotation (CE metric)
Superstructure rotation (CE metric)
Tailswing (CE metric)
Raise/lower time (CE Metric)
Inside turning radius (CE metric)
Outside turning radius (CE metric)
Tires (CE metric)
Controls (CE metric)
Drive system (CE metric)
Power source (CE Metric)
Weight (CE Metric)
Max. working height
86 ft
Max. platform height
80 ft
Max. horizontal reach
71 ft 2 in
Platform size
8 ft x 3 ft
Ground clearance
13 in
Platform capacity (SWL)
500 lbs
Overall width
8 ft 6 in
Overall length
38 ft 8 in
Max. wind speed
28 mph
Max. drive height
80 ft
Max. drive speed (elevated)
0.6 mph
Max. drive speed (stowed)
3.0 mph
Raise / lower time
195 / 175 sec
Gradeability
40%
Jib length
n/a
Jib arc
n/a
Platform rotation
170°
Superstructure rotation
360° continuous
Tailswing
78.5 in
Inside turning radius
7 ft 10 in
Outside turning radius
15 ft 6 in
Tires
15 x 625 foam filled lug
Controls
Proportional joystick
Drive system
4 wheel drive
Power source
Kubota V2403 59hp diesel - Tier 4 Final
Weight
36,332 lbs

Specifications subject to change without notice. The equipment hereunder have been subject to limited testing, and any performance specifications and representations are the result of limited testing. Photos and diagrams are shown for illustrative purposes only. Snorkel makes no warranty, representation, or guarantee regarding the information contained herein or the suitability of its equipment for any particular purpose. It is the Buyer’s responsibility to independently determine suitability of any equipment or parts, and to test and verify the same. Refer to appropriate Snorkel operator’s manual for detailed instructions on the proper use and maintenance.

Last Updated
02/2019

Standard Features

  • Snorkel GuardTM secondary guarding system
  • Four wheel drive, steer and crab steer
  • Hydraulic platform rotation
  • 360° continuous turntable rotation
  • Drive motion alarm
  • Flashing amber light
  • Foam filled lug tires
  • Proportional drive, boom lift, swing & extend
  • Rheostat control for jib & platform level
  • Power line to platform
  • 5° tilt alarm
  • Tri-entry platform
  • Dual lanyard attachment points
  • Hour meter & on-board diagnostics display
  • Horn
  • 2 year parts & labor, 5 year structural warranty

Options

  • Special paint colors
  • Airline to platform
  • AC generator 110V/240V 2kW
  • Non-marking tires
  • Cold weather package
  • Extreme cold weather package
  • Extreme environment package
  • Light package
  • Tow kit
  • Dual fuel
  • Glazier package
  • Utility package
  • 12k Generator package
  • 12k Generator/Welder package
  • Environmental hydraulic oil
  • Tool tray
  • CSA compliant
