TB126J
132 ft Working Height
500 lbs Platform Capacity
42,150 lbs Weight

TB126J

The Snorkel TB126J is the largest model in the line of telescopic boom lifts. The TB126J offers the highest working height in the family with a jib for added outreach. Designed for construction applications, a powerful diesel engine comes as standard, along with a fixed front axle and extendable rear axle.

Specifications

Max. working height
Max. platform height
Max. horizontal reach
Platform size
Overall width
Operational width
Overall length
Stowed height
Ground clearance
Platform capacity (SWL)
Max. drive height
Max. wind speed
Max. drive speed (stowed)
Max. drive speed (elevated)
Jib length
Jib arc
Platform rotation
Superstructure rotation
Tailswing (axles retracted)
Tailswing (axles extended)
Raise/lower time
Gradeability
Inside turning radius
Outside turning radius
Tires
Controls
Drive system
Power source
Weight
Max. working height (ANSI metric)
Max. platform height (ANSI metric)
Max. horizontal reach (ANSI metric)
Platform size (ANSI metric)
Overall width (ANSI metric)
Stowed Height (ANSI Metric)
Ground clearance (ANSI metric)
Platform capacity (SWL - ANSI metric)
Max. wind speed (ANSI metric)
Max. drive height (ANSI metric)
Max. drive speed (stowed) (ANSI metric)
Max. drive speed (elevated) (ANSI metric)
Jib length (ANSI metric)
Jib arc (ANSI metric)
Platform rotation (ANSI metric)
Superstructure rotation (ANSI metric)
Tailswing (axles retracted) (ANSI metric)
Tailswing (axles extended) (ANSI metric)
Raise/lower time (ANSI Metric)
Gradeability (ANSI metric)
Inside turning radius (ANSI metric)
Outside turning radius (ANSI metric)
Tires (ANSI metric)
Controls (ANSI metric)
Drive system (ANSI metric)
Power source (ANSI Metric)
Weight (ANSI Metric)
Max. working height (CE Imperial)
Max. platform height (CE imperial)
Max. horizontal reach (CE imperial)
Platform size (CE imperial)
Overall width (CE imperial)
Overall width (extended) (CE imperial)
Stowed Height (CE Imperial)
Ground clearance (CE imperial)
Platform capacity (SWL - CE Imperial)
Max. wind speed (CE imperial)
Max. drive height (CE imperial)
Max. drive speed (stowed) (CE imperial)
Max. drive speed (elevated) (CE imperial)
Jib length (CE imperial)
Jib arc (CE imperial)
Platform rotation (CE imperial)
Superstructure rotation (CE imperial)
Tailswing (axles retracted) (CE imperial)
Tailswing (axles extended) (CE imperial)
Raise/lower time (CE Imperial)
Gradeability (CE imperial)
Inside turning radius (CE imperial)
Outside turning radius (CE imperial)
Tires (CE imperial)
Controls (CE imperial)
Drive system (CE imperial)
Power source (CE Imperial)
Weight (CE imperial)
Max. platform height (CE metric)
Max. working height (CE metric)
Platform size (CE metric)
Overall width (CE metric)
Overall width (extended) (CE metric)
Stowed Height (CE Metric)
Ground clearance (CE metric)
Platform capacity (SWL - CE Metric)
Max. wind speed (CE metric)
Max. drive height (CE metric)
Max. drive speed (stowed) (CE metric)
Max. drive speed (elevated) (CE metric)
Jib length (CE metric)
Jib arc (CE metric)
Platform rotation (CE metric)
Superstructure rotation (CE metric)
Raise/lower time (CE Metric)
Inside turning radius (CE metric)
Outside turning radius (CE metric)
Tires (CE metric)
Controls (CE metric)
Drive system (CE metric)
Power source (CE Metric)
Weight (CE Metric)
Max. working height
132 ft
Max. platform height
126 ft
Max. horizontal reach
62 ft 11 in
Platform size
8 ft x 3 ft
Stowed height
10 ft 5 in
Ground clearance
13 in
Platform capacity (SWL)
500 lbs
Overall width
8 ft 6 in
Overall length
44 ft 9 in
Max. wind speed
28 mph
Max. drive height
126 ft
Max. drive speed (elevated)
0.15 mph
Max. drive speed (stowed)
2.9 mph
Raise / lower time
208 / 215 sec
Gradeability
30%
Jib length
6 ft 6 in
Jib arc
135° (+70°/-65°)
Platform rotation
150°
Superstructure rotation
360° continuous
Inside turning radius
21 ft 2.4 in
Outside turning radius
33 ft
Tires
445-65 D22.5 foam filled lug
Controls
Proportional joystick
Drive system
4 wheel drive
Power source
Kubota V2403 59hp diesel - Tier 4 Final
Weight
42,150 lbs

Specifications subject to change without notice. The equipment hereunder have been subject to limited testing, and any performance specifications and representations are the result of limited testing. Photos and diagrams are shown for illustrative purposes only. Snorkel makes no warranty, representation, or guarantee regarding the information contained herein or the suitability of its equipment for any particular purpose. It is the Buyer’s responsibility to independently determine suitability of any equipment or parts, and to test and verify the same. Refer to appropriate Snorkel operator’s manual for detailed instructions on the proper use and maintenance.

Last Updated
02/2019

Standard Features

  • Snorkel GuardTM secondary guarding system
  • 6 ́ 6 ̋ 135° jib (TB126J only)
  • Four wheel drive, braking & fixed front steering
  • Hydraulic platform rotation
  • 360° continuous turntable rotation
  • Hydraulic extended rear axles w/ boom interlocks
  • Built-in jack for raising chassis
  • Flashing amber light
  • Proportional drive, lift, swing, extend & jib (if equipped)
  • Dual lanyard attachment points
  • Foam filled lug tires
  • Power line to platform
  • 2 year parts & labor, 5 year structural warranty

Options

  • Special paint colors
  • Airline to platform
  • Non-marking tires
  • AC generator 110V/240V 2kW
  • Cold weather package
  • Extreme cold weather package
  • Extreme environment package
  • Light package
  • Glazier package
  • Utility package
  • 12k Generator package
  • 12k Generator/Welder package
  • Tow kit
  • Environmental hydraulic oil
  • Tool tray
  • CSA compliant
