66 ft 8 in

Working Height

600 lbs

Platform Capacity

28,659 lbs

Weight

600S All Terrain

The Snorkel 600S All Terrain telescopic boom lift is fitted with four independent rubber tracks. Easily tackling soft and sensitive environments, this boom lift offers superb maneuverability without sinking or disturbing the ground. Developed with a high torque hydraulic pump, it also has excellent gradeability and can climb gradients up to 45%.

Max. working height
66 ft 8 in
Max. platform height
60 ft 8 in
Max. horizontal reach
52 ft 7 in
Platform size
8 ft x 3 ft
Overall length
30 ft 1 in
Overall width
8 ft 1 in
Transport Width
7 ft 4 in
Transport Length
30 ft 1 in
Transport Height
8 ft 7 in
Stowed height
8 ft 7 in
Ground clearance
17.5 in
Platform capacity – unrestricted
600 lbs
Platform capacity – restricted
1,000 lbs
Max. drive height
60 ft 8 in
Max. wind speed
28 mph
Max. drive speed (elevated)
0.6 mph
Max. drive speed (stowed)
3.5 mph
Raise / lower time
50 / 50 seconds
Gradeability
45%
Jib length
n/a
Jib arc
n/a
Platform rotation
150°
Superstructure rotation
360° continuous
Tailswing
47 in
Inside turning radius
19 ft 6 in
Outside turning radius
27 ft 6 in
Tires
Independent rubber tracks
Controls
Proportional drive, raise, slew, extend, jib and platform rotate
Drive system
4 track drive
Power source
Deutz 74HP (55KW) turbo diesel T4F
Auxiliary power unit
12V DC
Weight
28,659 lbs
Specifications subject to change without notice. The equipment hereunder have been subject to limited testing, and any performance specifications and representations are the result of limited testing. Photos and diagrams are shown for illustrative purposes only. Snorkel makes no warranty, representation, or guarantee regarding the information contained herein or the suitability of its equipment for any particular purpose. It is the Buyer’s responsibility to independently determine suitability of any equipment or parts, and to test and verify the same. Refer to appropriate Snorkel operator’s manual for detailed instructions on the proper use and maintenance.
Last Updated
06/2021
  • Snorkel Guard™ secondary guarding system
  • Oscillating axle (8˝ of oscillation)
  • Hydraulic platform rotation
  • Hydraulic oil cooler
  • 4-track drive
  • All proportional controls
  • Swing-out engine tray
  • Motion alarm
  • Horn
  • Hour meter & on-board diagnostics display
  • Power line to platform
  • 5º tilt alarm & cut out
  • Hour meter & on-board diagnostics display
  • DC emergency operation
  • Tri-entry platform
  • Flashing amber light
  • Platform overload system
  • 2 year parts & labor, 5 year structural warranty
Extreme Environment Package
Aircraft Package
Glazier Package
Deluxe Aircraft Package
Pipe Rack
Cold Weather Package
Extreme Cold Weather Package
Environmental hydraulic oil
Airline to platform
AC generator 110V/220V 2kW
Tool tray
Special paint colors
10kW generator/welder package
10kW generator package
