Snorkel 2100SJ Astounding Accessibility
216 ft Working Height
660 lbs Platform Capacity
80,000 lbs Weight

2100SJ

The Snorkel 2100SJ is Snorkel's largest diesel telescopic boom lift with patented design features. With an impressive reach and lift height, exceptional up and over capabilities offer a maximum horizontal reach up to 100 ft. (30.5m) with a 30 ft. (9.1m) jib boom. Two control panels on the platform allow for safe operation while working at height. Robust 4-wheel drive and multiple steering modes deliver superb rough terrain performance with a tight inside turning radius for excellent maneuverability. Its innovative wheel extension and narrow wheelbase provide stability on the job and ease of transportation.

Specifications

Max. working height
216 ft
Max. platform height
210 ft
Max. horizontal reach
100 ft
Platform size
8 ft x 3 ft
Stowed height
10 ft
Ground clearance
9 in
Platform capacity - unrestricted
660 lbs
Platform capacity - restricted
1,000 lbs
Max. drive height
210 ft
Max. wind speed
28 mph
Max. drive speed (elevated)
0.15 mph
Max. drive speed (stowed)
2.7 mph
Raise / lower time
6.5 / 7 min
Gradeability
35%
Jib length
30 ft
Platform rotation
150°
Superstructure rotation
360° continuous
Tires
445/50-710 foam filled 24 ply
Controls
Proportional joystick
Drive system
4 wheel drive
Power source
Deutz TCD 2.9L 74hp - Tier 4 Final
Weight
80,000 lbs

Specifications subject to change without notice. The equipment hereunder have been subject to limited testing, and any performance specifications and representations are the result of limited testing. Photos and diagrams are shown for illustrative purposes only. Snorkel makes no warranty, representation, or guarantee regarding the information contained herein or the suitability of its equipment for any particular purpose. It is the Buyer’s responsibility to independently determine suitability of any equipment or parts, and to test and verify the same. Refer to appropriate Snorkel operator’s manual for detailed instructions on the proper use and maintenance.

Last Updated
03/2020

Standard Features

  • Snorkel Guard™ secondary guarding system
  • Secondary platform controls
  • Four wheel drive
  • Hydraulic platform rotation
  • 5 steering modes – front axle, rear axle, crab, complementary & lateral
  • 360º continuous turntable rotation
  • All proportional controls
  • Tool tray
  • Remote lower control panel
  • Flashing amber light
  • Dual lanyard attachment points
  • Foam filled tires
  • Power line to platform
  • 2 year parts & labor, 5 year structural warranty

Options

  • Special paint colors
  • Airline to platform
  • Non-marking tires
  • AC generator 110V/220V 2kW
  • 100hp engine option
  • Pressure washing package
  • 10kW generator package
  • 10kW generator/welder package
  • Cold weather package
  • Extreme cold weather package
  • Extreme environment package
  • Light package
  • Glazier package
  • Environmental hydraulic oil
