MB26J
31 ft 6 in Working Height
475 lbs Platform Capacity
7,000 lbs Weight

MB26J

The Snorkel MB26J is a versatile electric mast boom lift. Designed for applications requiring up-and-over capabilities, the lift is fitted with a jib for working in confined spaces. A 360° mast rotation adds maneuverability for even more precision.

Specifications

Max. working height
Max. platform height
Max. horizontal reach
Platform size
Overall length
Overall width
Stowed height
Ground clearance
Platform capacity (SWL)
Max. drive height
Max. wind speed
Max. drive speed (stowed)
Max. drive speed (elevated)
Jib length
Jib arc
Mast rotation (non-continuous)
Raise/lower time
Gradeability
Inside turning radius
Outside turning radius
Tires
Controls
Drive system
Power source
Weight
Max. working height (ANSI metric)
Max. platform height (ANSI metric)
Max. horizontal reach (ANSI metric)
Platform size (ANSI metric)
Overall width (ANSI metric)
Overall length (ANSI metric)
Stowed Height (ANSI Metric)
Ground clearance (ANSI metric)
Platform capacity (SWL - ANSI metric)
Max. wind speed (ANSI metric)
Max. drive height (ANSI metric)
Max. drive speed (stowed) (ANSI metric)
Jib length (ANSI metric)
Jib arc (ANSI metric)
Mast rotation (non-continuous) (ANSI metric)
Raise/lower time (ANSI Metric)
Gradeability (ANSI metric)
Inside turning radius (ANSI metric)
Outside turning radius (ANSI metric)
Tires (ANSI metric)
Controls (ANSI metric)
Drive system (ANSI metric)
Power source (ANSI Metric)
Weight (ANSI Metric)
Max. working height (CE Imperial)
Max. platform height (CE imperial)
Max. horizontal reach (CE imperial)
Platform size (CE imperial)
Overall width (CE imperial)
Overall length (CE imperial)
Stowed Height (CE Imperial)
Ground clearance (CE imperial)
Platform capacity (SWL - CE Imperial)
Max. wind speed (CE imperial)
Max. drive height (CE imperial)
Max. drive speed (stowed) (CE imperial)
Max. drive speed (elevated) (CE imperial)
Jib length (CE imperial)
Jib arc (CE imperial)
Mast rotation (non-continuous) (CE imperial)
Raise/lower time (CE Imperial)
Inside turning radius (CE imperial)
Outside turning radius (CE imperial)
Tires (CE imperial)
Controls (CE imperial)
Drive system (CE imperial)
Power source (CE Imperial)
Weight (CE imperial)
Max. working height (CE metric)
Max. platform height (CE metric)
Platform size (CE metric)
Overall width (CE metric)
Overall length (CE metric)
Stowed Height (CE Metric)
Ground clearance (CE metric)
Platform capacity (SWL - CE Metric)
Max. wind speed (CE metric)
Max. drive height (CE metric)
Max. drive speed (stowed) (CE metric)
Max. drive speed (elevated) (CE metric)
Jib length (CE metric)
Jib arc (CE metric)
Mast rotation (non-continuous) (CE metric)
Raise/lower time (CE Metric)
Inside turning radius (CE metric)
Outside turning radius (CE metric)
Tires (CE metric)
Controls (CE metric)
Drive system (CE metric)
Power source (CE Metric)
Weight (CE Metric)
Max. working height
31 ft 6 in
Max. platform height
25 ft 6 in
Max. horizontal reach
9 ft 10 in
Platform size
30 in x 28 in
Stowed height
6 ft 6 in
Ground clearance
4 in
Platform capacity (SWL)
475 lbs
Overall width
39 in
Overall length
9 ft 2 in
Max. wind speed
28 mph
Max. drive height
20 ft
Max. drive speed (elevated)
0.3 mph
Max. drive speed (stowed)
2.0 mph
Raise / lower time
56 / 27 sec
Gradeability
25%
Jib length
4 ft 7 in
Jib arc
130°
Inside turning radius
11 in
Outside turning radius
6 ft 10 in
Tires
13.5 x 4 non-marking rubber
Controls
Proportional controls
Drive system
Electro/hydraulic
Power source
4 x 6V x 375Ah batteries
Weight
7,000 lbs

Specifications subject to change without notice. The equipment hereunder have been subject to limited testing, and any performance specifications and representations are the result of limited testing. Photos and diagrams are shown for illustrative purposes only. Snorkel makes no warranty, representation, or guarantee regarding the information contained herein or the suitability of its equipment for any particular purpose. It is the Buyer’s responsibility to independently determine suitability of any equipment or parts, and to test and verify the same. Refer to appropriate Snorkel operator’s manual for detailed instructions on the proper use and maintenance.

Last Updated
02/2018

Standard Features

  • Ultra-tight inside turning radius
  • Proportional controls
  • Tilt alarm
  • Non-marking rubber tires
  • 2 persons indoors
  • 1 person outdoors
  • Self-seeking automatic battery charger
  • Automatic battery fill
  • Power line to platform
  • Hour meter & on-board diagnostics display
  • Hydraulic pothole protection system
  • 2 year parts & labor, 5 year structural warranty

Options

  • Special paint colors
  • Flashing amber light
  • Environmental green oil

Downloads

Specification Sheet (ANSI Metric)

English Français

Specification Sheet (ANSI Imperial)

English

Product Range Multifold (ANSI)

English Español
