Snorkel A46JE battery electric boom lift
52 ft 3 in Working Height
500 lbs Platform Capacity
14,690 lbs Weight

A46JE

The Snorkel A46JE is the battery-electric version of the A46JRT articulating boom lift. This 2WD self-propelled boom features a spacious platform that can easily lift two people with tools. An articulating jib and powered 160° platform rotation add versatility to the A46JE's quiet, emission-free operation.

Specifications
Max. working height
52 ft 3 in
Max. platform height
46 ft 3 in
Max. horizontal reach
24 ft 11 in
Clearance height at max. outreach
24 ft 6 in
Platform size
39 in x 72 in
Chassis width
5 ft 8 in
Overall length
18 ft 4 in
Stowed height
6 ft 7 in
Ground clearance
6 in
Platform capacity (SWL)
500 lbs
Max. drive height
46 ft 3 in
Max. wind speed
28 mph
Max. drive speed (elevated)
0.5 mph
Max. drive speed (stowed)
4.25 mph
Raise / lower time
99 / 92 seconds
Gradeability
30%
Jib length
5 ft
Jib arc
140°
Platform rotation
160°
Superstructure rotation
360° non-continuous
Tailswing
0 in
Inside turning radius
2 ft
Outside turning radius
9 ft 10 in
Tires
Non-marking foam filled IN240/55D 17.5
Controls
Proportional
Drive system
2-wheel drive
Power source
8 x 6V 360Ah batteries
Weight
14,690 lbs

Specifications subject to change without notice. The equipment hereunder have been subject to limited testing, and any performance specifications and representations are the result of limited testing. Photos and diagrams are shown for illustrative purposes only. Snorkel makes no warranty, representation, or guarantee regarding the information contained herein or the suitability of its equipment for any particular purpose. It is the Buyer’s responsibility to independently determine suitability of any equipment or parts, and to test and verify the same. Refer to appropriate Snorkel operator’s manual for detailed instructions on the proper use and maintenance.

Last Updated
12/2021

Standard Features

  • Snorkel Guard™ secondary guarding system
  • Multi-function proportional controls
  • Zero tailswing
  • Tri-entry platform
  • Non-marking tires
  • Power line to platform
  • Hour meter & on-board diagnostics display
  • Tilt alarm
  • Horn
  • Battery charge indicator
  • Drive motion alarm
  • Flashing amber light
  • Platform overload system
  • 2 year parts & labor, 5 year structural warranty

Options

  • Special paint colors
  • Airline to platform
  • 5’ aluminum platform with swing gate
  • Aircraft package
  • Deluxe aircraft package
  • Cold weather package
  • Extreme environmental package
  • Light package
  • Environmental hydraulic oil
  • Pipe rack
  • Snorkel OnSite™ telematics

Working Envelope

A46JE Working Envelope - ANSI IMP
