Highly Accessible - Snorkel AB80J
85 ft 11 in Working Height
500 lbs Platform Capacity
36,800 lbs Weight

AB80J

The Snorkel AB80J is a high-performing diesel articulated boom lift on all terrains. Excellent up-and-over capabilities and a jib boom offers precise reach where needed. Boasting both 4-wheel drive and 4-wheel steer, the AB80J delivers impressive rough terrain performance.

Specifications

Max. working height
Max. platform height
Max. horizontal reach
Clearance height at max. outreach
Platform size
Overall width
Overall length
Stowed height
Ground clearance
Platform capacity (SWL)
Max. wind speed
Max. drive height
Max. drive speed (stowed)
Max. drive speed (elevated)
Jib length
Jib arc
Jib rotation
Platform rotation
Superstructure rotation
Tailswing
Tailswing (riser boom elevated)
Tailswing (riser boom stowed)
Raise/lower time
Gradeability
Inside turning radius
Outside turning radius
Tires
Controls
Drive system
Power source
Weight
Max. working height (ANSI metric)
Max. platform height (ANSI metric)
Max. horizontal reach (ANSI metric)
Clearance height at max. outreach (ANSI metric)
Platform size (ANSI metric)
Overall length (ANSI metric)
Overall width (ANSI metric)
Stowed Height (ANSI Metric)
Ground clearance (ANSI metric)
Platform capacity (SWL - ANSI metric)
Max. wind speed (ANSI metric)
Max. drive height (ANSI metric)
Max. drive speed (stowed) (ANSI metric)
Max. drive speed (elevated) (ANSI metric)
Jib length (ANSI metric)
Jib arc (ANSI metric)
Platform rotation (ANSI metric)
Superstructure rotation (ANSI metric)
Raise/lower time (ANSI Metric)
Gradeability (ANSI metric)
Inside turning radius (ANSI metric)
Outside turning radius (ANSI metric)
Tires (ANSI metric)
Controls (ANSI metric)
Drive system (ANSI metric)
Power source (ANSI Metric)
Weight (ANSI Metric)
Max. working height (CE Imperial)
Max. platform height (CE imperial)
Max. horizontal reach (CE imperial)
Clearance height at max. outreach (CE imperial)
Platform size (CE imperial)
Overall width (CE imperial)
Overall length (CE imperial)
Stowed Height (CE Imperial)
Ground clearance (CE imperial)
Platform capacity (SWL - CE Imperial)
Max. wind speed (CE imperial)
Max. drive height (CE imperial)
Max. drive speed (stowed) (CE imperial)
Max. drive speed (elevated) (CE imperial)
Jib length (CE imperial)
Jib arc (CE imperial)
Platform rotation (CE imperial)
Superstructure rotation (CE imperial)
Tailswing (CE imperial)
Raise/lower time (CE Imperial)
Gradeability (CE imperial)
Inside turning radius (CE imperial)
Outside turning radius (CE imperial)
Tires (CE imperial)
Controls (CE imperial)
Drive system (CE imperial)
Power source (CE Imperial)
Weight (CE imperial)
Max. working height (CE metric)
Max. platform height (CE metric)
Clearance height at max. outreach (CE metric)
Platform size (CE metric)
Overall width (CE metric)
Overall length (CE metric)
Stowed Height (CE Metric)
Ground clearance (CE metric)
Max. wind speed (CE metric)
Max. drive height (CE metric)
Max. drive speed (stowed) (CE metric)
Max. drive speed (elevated) (CE metric)
Jib length (CE metric)
Jib arc (CE metric)
Jib rotation (CE metric)
Platform rotation (CE metric)
Superstructure rotation (CE metric)
Tailswing (CE metric)
Raise/lower time (CE Metric)
Gradeability (CE metric)
Inside turning radius (CE metric)
Outside turning radius (CE metric)
Tires (CE metric)
Controls (CE metric)
Drive system (CE metric)
Power source (CE Metric)
Weight (CE Metric)
Max. working height
85 ft 11 in
Max. platform height
79 ft 11 in
Max. horizontal reach
59 ft 5 in
Clearance height at max. outreach
27 ft 11 in
Platform size
8 ft x 3 ft
Stowed height
9 ft 10 in
Ground clearance
13 in
Platform capacity (SWL)
500 lbs
Overall width
8 ft 6 in
Overall length
32 ft 2 in
Max. wind speed
28 mph
Max. drive height
79 ft 11 in
Max. drive speed (elevated)
0.6 mph
Max. drive speed (stowed)
3.0 mph
Raise / lower time
240 / 240 sec
Gradeability
30%
Jib length
5 ft
Jib rotation
n/a
Jib arc
140°
Platform rotation
150°
Superstructure rotation
360° continuous
Tailswing
35 in
Tailswing (riser boom elevated)
0 in
Tailswing (riser boom stowed)
60 in
Inside turning radius
7 ft 10 in
Outside turning radius
15 ft 5 in
Tires
15 x 625 foam filled lug
Controls
Proportional joystick
Drive system
4 wheel drive
Power source
Kubota V2403 65hp diesel - Tier 4 Final
Weight
36,800 lbs

Specifications subject to change without notice. The equipment hereunder have been subject to limited testing, and any performance specifications and representations are the result of limited testing. Photos and diagrams are shown for illustrative purposes only. Snorkel makes no warranty, representation, or guarantee regarding the information contained herein or the suitability of its equipment for any particular purpose. It is the Buyer’s responsibility to independently determine suitability of any equipment or parts, and to test and verify the same. Refer to appropriate Snorkel operator’s manual for detailed instructions on the proper use and maintenance.

Last Updated
02/2019

Standard Features

  • Snorkel GuardTM secondary guarding system
  • Hydraulic platform rotation
  • Four wheel drive, steer and crab steer
  • Foam filled lug tires
  • 360° continuous turntable rotation
  • Proportional drive, lift & swing, extend & rotate
  • Drive motion alarm
  • Flashing amber light
  • Horn
  • Dual lanyard attachment points
  • Power line to platform
  • 5° tilt alarm
  • 2 year parts & labor, 5 year structural warranty

Options

  • Special paint colors
  • Airline to platform
  • Non-marking tires
  • AC generator 110V/240V 2kW
  • Aircraft package
  • Deluxe aircraft package
  • Cold weather package
  • Extreme cold weather package
  • Extreme environment package
  • Light package
  • Tow kit
  • Glazier package
  • Utility package
  • 12k Generator package
  • 12k Generator/Welder package
  • Dual fuel
  • Environmental hydraulic oil
  • Tool tray
  • CSA compliant
