Unfolding Flexibility - Snorkel AB60J
65 ft 9 in Working Height
500 lbs Platform Capacity
24,800 lbs Weight

AB60J

The robust and reliable Snorkel AB60J articulating boom lift easily reaches up and over obstacles. Designed tough for the rental industry, it is simple to operate and maintain. Ideal for both maintenance and construction applications, the lift offers versatile performance on all jobsites.

Specifications

Max. working height
Max. platform height
Max. horizontal reach
Clearance height at max. outreach
Platform size
Overall width
Overall length
Stowed height
Ground clearance
Platform capacity (SWL)
Max. wind speed
Max. drive height
Max. drive speed (stowed)
Max. drive speed (elevated)
Jib length
Jib arc
Platform rotation
Superstructure rotation
Tailswing (riser boom elevated)
Tailswing (riser boom stowed)
Raise/lower time
Gradeability
Inside turning radius
Outside turning radius
Tires
Controls
Drive system
Power source
Weight
Max. working height (ANSI metric)
Max. platform height (ANSI metric)
Max. horizontal reach (ANSI metric)
Clearance height at max. outreach (ANSI metric)
Platform size (ANSI metric)
Chassis width (ANSI metric)
Overall length (ANSI metric)
Stowed Height (ANSI Metric)
Ground clearance (ANSI metric)
Platform capacity (SWL - ANSI metric)
Max. wind speed (ANSI metric)
Max. drive height (ANSI metric)
Max. drive speed (stowed) (ANSI metric)
Max. drive speed (elevated) (ANSI metric)
Jib length (ANSI metric)
Jib arc (ANSI metric)
Superstructure rotation (ANSI metric)
Tailswing (riser boom elevated) (ANSI metric)
Raise/lower time (ANSI Metric)
Gradeability (ANSI metric)
Inside turning radius (ANSI metric)
Outside turning radius (ANSI metric)
Tires (ANSI metric)
Controls (ANSI metric)
Drive system (ANSI metric)
Power source (ANSI Metric)
Weight (ANSI Metric)
Max. working height (CE Imperial)
Max. platform height (CE imperial)
Max. horizontal reach (CE imperial)
Clearance height at max. outreach (CE imperial)
Platform size (CE imperial)
Chassis width (CE imperial)
Overall length (CE imperial)
Stowed Height (CE Imperial)
Ground clearance (CE imperial)
Platform capacity (SWL - CE Imperial)
Max. wind speed (CE imperial)
Max. drive height (CE imperial)
Max. drive speed (stowed) (CE imperial)
Max. drive speed (elevated) (CE imperial)
Jib length (CE imperial)
Jib arc (CE imperial)
Platform rotation (CE imperial)
Superstructure rotation (CE imperial)
Tailswing (riser boom elevated) (CE imperial)
Raise/lower time (CE Imperial)
Gradeability (CE imperial)
Inside turning radius (CE imperial)
Outside turning radius (CE imperial)
Tires (CE imperial)
Drive system (CE imperial)
Power source (CE Imperial)
Weight (CE imperial)
Max. working height (CE metric)
Max. platform height (CE metric)
Clearance height at max. outreach (CE metric)
Platform size (CE metric)
Chassis width (CE metric)
Overall length (CE metric)
Ground clearance (CE metric)
Max. wind speed (CE metric)
Max. drive height (CE metric)
Max. drive speed (stowed) (CE metric)
Max. drive speed (elevated) (CE metric)
Jib length (CE metric)
Jib arc (CE metric)
Superstructure rotation (CE metric)
Raise/lower time (CE Metric)
Inside turning radius (CE metric)
Outside turning radius (CE metric)
Tires (CE metric)
Controls (CE metric)
Drive system (CE metric)
Power source (CE Metric)
Weight (CE Metric)
Max. working height
65 ft 9 in
Max. platform height
60 ft
Max. horizontal reach
43 ft 1 in
Clearance height at max. outreach
19 ft 6 in
Platform size
8 ft x 3 ft
Stowed height
8 ft 3 in
Ground clearance
12 in
Platform capacity (SWL)
500 lbs
Overall width
7 ft 11.5 in
Overall length
29 ft 2 in
Max. wind speed
28 mph
Max. drive height
60 ft
Max. drive speed (elevated)
0.6 mph
Max. drive speed (stowed)
3.2 mph
Raise / lower time
125 / 121 sec
Gradeability
30%
Jib length
6 ft
Jib arc
75°
Platform rotation
180°
Superstructure rotation
360° continuous
Tailswing (riser boom elevated)
0 in
Tailswing (riser boom stowed)
60 in
Inside turning radius
13 ft 3 in
Outside turning radius
20 ft 3 in
Tires
15 in x 19.5 in foam filled lug
Controls
Proportional joystick drive, lift & rotation
Drive system
4 wheel drive
Power source
Kubota V2403M-T 44kW/59hp - Tier 4 Final
Weight
24,800 lbs

Specifications subject to change without notice. The equipment hereunder have been subject to limited testing, and any performance specifications and representations are the result of limited testing. Photos and diagrams are shown for illustrative purposes only. Snorkel makes no warranty, representation, or guarantee regarding the information contained herein or the suitability of its equipment for any particular purpose. It is the Buyer’s responsibility to independently determine suitability of any equipment or parts, and to test and verify the same. Refer to appropriate Snorkel operator’s manual for detailed instructions on the proper use and maintenance.

Last Updated
02/2019

Standard Features

  • Snorkel GuardTM secondary guarding system
  • 6ft, 75° jib
  • Hydraulic platform rotation
  • 360° continuous turntable rotation
  • Proportional drive, lift & swing
  • Dual lanyard attachment points
  • Horn
  • Rheostat control at ground for boom functions
  • Power line to platform
  • 5° tilt alarm
  • Drive motion alarm
  • Flashing amber light
  • 2 year parts & labor, 5 year structural warranty

Options

  • Special paint colors
  • Airline to platform
  • Non-marking tires
  • AC generator 110V/240V 2kW
  • Aircraft package
  • Deluxe aircraft package
  • Cold weather package
  • Extreme cold weather package
  • Extreme environment package
  • Light package
  • Tow kit
  • Glazier package
  • Utility package
  • Dual fuel
  • Environmental hydraulic oil
  • Tool tray
  • CSA compliant
