Reliable Range - Snorkel A62JRT
67 ft 8 in Working Height
500 lbs Platform Capacity
23,500 lbs Weight

A62JRT

The Snorkel A62JRT articulating boom lift delivers a superb working envelope with zero tailswing. Offering the largest platform in its class, it can lift two people with tools to a working height of 67 ft. 8 in. (20.8m). A compact length when stowed makes it easy to transport the lift between jobsites. An oscillating front axle keeps the A62JRT steady on uneven ground for all-terrain performance.

Specifications

Max. working height
Max. platform height
Max. horizontal reach
Clearance height at max. outreach
Platform size
Overall width
Overall length
Stowed height
Ground clearance
Platform capacity (SWL)
Max. wind speed
Max. drive height
Max. drive speed (stowed)
Max. drive speed (elevated)
Jib length
Jib arc
Platform rotation
Superstructure rotation
Tailswing
Gradeability
Inside turning radius
Outside turning radius
Tires
Controls
Drive system
Power source
Weight
Max. working height (ANSI metric)
Max. platform height (ANSI metric)
Max. horizontal reach (ANSI metric)
Clearance height at max. outreach (ANSI metric)
Platform size (ANSI metric)
Overall width (ANSI metric)
Stowed Height (ANSI Metric)
Ground clearance (ANSI metric)
Platform capacity (SWL - ANSI metric)
Max. wind speed (ANSI metric)
Max. drive speed (stowed) (ANSI metric)
Max. drive speed (elevated) (ANSI metric)
Jib length (ANSI metric)
Jib arc (ANSI metric)
Platform rotation (ANSI metric)
Gradeability (ANSI metric)
Inside turning radius (ANSI metric)
Outside turning radius (ANSI metric)
Tires (ANSI metric)
Controls (ANSI metric)
Drive system (ANSI metric)
Power source (ANSI Metric)
Weight (ANSI Metric)
Max. working height (CE Imperial)
Max. platform height (CE imperial)
Max. horizontal reach (CE imperial)
Clearance height at max. outreach (CE imperial)
Platform size (CE imperial)
Overall width (CE imperial)
Overall length (CE imperial)
Stowed Height (CE Imperial)
Ground clearance (CE imperial)
Max. wind speed (CE imperial)
Max. drive height (CE imperial)
Max. drive speed (stowed) (CE imperial)
Max. drive speed (elevated) (CE imperial)
Jib length (CE imperial)
Jib arc (CE imperial)
Tailswing (CE imperial)
Gradeability (CE imperial)
Inside turning radius (CE imperial)
Outside turning radius (CE imperial)
Tires (CE imperial)
Drive system (CE imperial)
Power source (CE Imperial)
Weight (CE imperial)
Max. working height (CE metric)
Max. platform height (CE metric)
Max. horizontal reach (CE metric)
Clearance height at max. outreach (CE metric)
Platform size (CE metric)
Overall width (CE metric)
Stowed Height (CE Metric)
Ground clearance (CE metric)
Platform capacity (SWL - CE Metric)
Max. wind speed (CE metric)
Max. drive height (CE metric)
Max. drive speed (stowed) (CE metric)
Max. drive speed (elevated) (CE metric)
Jib length (CE metric)
Jib arc (CE metric)
Tailswing (CE metric)
Inside turning radius (CE metric)
Outside turning radius (CE metric)
Tires (CE metric)
Controls (CE metric)
Drive system (CE metric)
Power source (CE Metric)
Weight (CE Metric)
Max. working height
67 ft 8 in
Max. platform height
61 ft 8 in
Max. horizontal reach
36 ft 6 in
Clearance height at max. outreach
29 ft 6 in
Platform size
8 ft x 3 ft
Stowed height
8 ft 5 in
Ground clearance
1 ft 2 in
Platform capacity (SWL)
500 lbs
Overall width
8 ft
Overall length
28 ft 2.5 in
Max. wind speed
28 mph
Max. drive height
61 ft 8 in
Max. drive speed (elevated)
0.75 mph
Max. drive speed (stowed)
3.8 mph
Gradeability
45%
Jib length
6 ft
Jib arc
136°
Platform rotation
180°
Superstructure rotation
360° continuous
Tailswing
0 in
Inside turning radius
4 ft 6 in
Outside turning radius
15 ft 5 in
Tires
355/55 D625 foam filled lug
Controls
Multi-function proportional drive, raise and slew
Drive system
4 wheel drive hydrostatic with oscillating axle
Power source
Kubota V2403M 36.5kW/48.9HP - Tier 4i
Weight
23,500 lbs

Specifications subject to change without notice. The equipment hereunder have been subject to limited testing, and any performance specifications and representations are the result of limited testing. Photos and diagrams are shown for illustrative purposes only. Snorkel makes no warranty, representation, or guarantee regarding the information contained herein or the suitability of its equipment for any particular purpose. It is the Buyer’s responsibility to independently determine suitability of any equipment or parts, and to test and verify the same. Refer to appropriate Snorkel operator’s manual for detailed instructions on the proper use and maintenance.

Last Updated
02/2018

Standard Features

  • Snorkel Guard™ secondary guarding system
  • Powerful hydrostatic 4 wheel drive
  • Oscillating axle
  • Zero tailswing
  • Ultra-tight turning radius
  • Swing-out engine tray
  • Hour meter
  • Motion alarm
  • Horn
  • Power line to platform
  • Flashing amber light
  • Tri-entry platform
  • DC emergency operation
  • 2 year parts & labour, 5 year structural warranty
  • CE approved

Options

  • Special paint colours
  • Airline to platform
  • AC generator 110V/240V 2kW
  • Aircraft package
  • Deluxe aircraft package
  • Cold weather package
  • Extreme cold weather package
  • Extreme environment package
  • Light package
  • Glazier package
  • Environmental hydraulic oil
