A46JRT
52 ft 11 in Working Height
500 lbs Platform Capacity
16,620 lbs Weight

A46JRT

The class-leading Snorkel A46JRT articulating boom lift delivers precise reach and powerful rough terrain performance. Its up-and-over capabilities provide exceptional maneuverability with an articulated jib as standard for extended reach. A tight turning radius and zero tailswing makes the A46JRT a flexible and versatile machine for hard-to-reach places.

Specifications

Max. working height
52 ft 11 in
Max. platform height
46 ft 11 in
Max. horizontal reach
24 ft 11 in
Clearance height at max. outreach
25 ft 2 in
Platform size
39 in x 72 in
Chassis width
6 ft 10 in
Overall length
18 ft 4 in
Stowed height
7 ft 2 in
Ground clearance
13 in
Platform capacity (SWL)
500 lbs
Max. drive height
46 ft 11 in
Max. wind speed
28 mph
Max. drive speed (elevated)
0.8 mph
Max. drive speed (stowed)
4.0 mph
Raise / lower time
101 / 98 sec
Gradeability
40%
Jib length
5 ft
Jib arc
140°
Platform rotation
160°
Superstructure rotation
360° non-continuous
Tailswing
0 in
Inside turning radius
2 ft 8 in
Outside turning radius
10 ft 5 in
Tires
Foam filled lug 355/55D625
Controls
Proportional
Drive system
4 wheel drive
Power source
Kubota V1505 24.9hp diesel - Tier 4 Final
Weight
16,620 lbs

Specifications subject to change without notice. The equipment hereunder have been subject to limited testing, and any performance specifications and representations are the result of limited testing. Photos and diagrams are shown for illustrative purposes only. Snorkel makes no warranty, representation, or guarantee regarding the information contained herein or the suitability of its equipment for any particular purpose. It is the Buyer’s responsibility to independently determine suitability of any equipment or parts, and to test and verify the same. Refer to appropriate Snorkel operator’s manual for detailed instructions on the proper use and maintenance.

Last Updated
02/2019

Standard Features

  • Snorkel GuardTM secondary guarding system
  • Multi-function proportional controls
  • Oscillating front axle (A46JRT only)
  • Tri-entry platform
  • Foam filled lug tires (A46JRT only)
  • Power line to platform
  • Hour meter & on-board diagnostics display
  • Tilt alarm
  • Horn
  • Battery charge indicator (A46JE)
  • Drive motion alarm
  • Flashing amber light
  • 2 year parts & labor, 5 year structural warranty

Options

  • Special paint colors
  • Airline to platform (A46JRT only)
  • Non-marking tires (A46JRT only)
  • Pneumatic tires (A46JRT only)
  • 5’ aluminum platform swing gate
  • AC generator 110V/240V 2kW (A46JRT only)
  • Dual fuel
  • Aircraft package
  • Deluxe aircraft package
  • Cold weather package
  • Extreme cold weather package (A46JRT only)
  • Extreme environmental package
  • Light package
  • Utility package (A46JRT)
  • Environmental hydraulic oil
  • Tool tray (A46JRT)
  • CSA compliant
