Simply Mobile - Snorkel S3006P
12 ft 6 in Working Height
529 lbs Platform Capacity
682 lbs Weight

S3006P

The Snorkel S3006P push-around mini scissor lift is ideal for indoor, low level working at height. With a compact design, this mini scissor lift can be transported in a passenger elevator, making it ideal for multi-story fit-out projects or maintenance applications in large buildings. Heavy-duty and robust, the S3006P withstands the demands of construction sites and the rental industry.

Specifications

Max. working height
Max. platform height
Platform capacity (SWL)
Overall width
Overall length
Stowed height
Max. wind speed
Raise/lower time
Power source
Charger
Weight
Max. working height (ANSI metric)
Max. platform height (ANSI metric)
Platform capacity (SWL - ANSI metric)
Overall width (ANSI metric)
Overall length (ANSI metric)
Stowed Height (ANSI Metric)
Max. wind speed (ANSI metric)
Raise/lower time (ANSI Metric)
Power source (ANSI Metric)
Charger (ANSI metric) -- NOTE: **Charger (CE metric) is out of alphabetical order - see next page
Weight (ANSI Metric)
Max. working height (CE Imperial)
Max. platform height (CE imperial)
Platform capacity (SWL - CE Imperial)
Overall width (CE imperial)
Overall length (CE imperial)
Stowed Height (CE Imperial)
Max. wind speed (CE imperial)
Raise/lower time (CE Imperial)
Power source (CE Imperial)
Charger (CE imperial)
Weight (CE imperial)
Max. working height (CE metric)
Max. platform height (CE metric)
Platform capacity (SWL - CE Metric)
Overall width (CE metric)
Overall length (CE metric)
Stowed Height (CE Metric)
Max. wind speed (CE metric)
Raise/lower time (CE Metric)
Power source (CE Metric)
**Charger (CE metric) (**out of alphabetical order)
Weight (CE Metric)
Max. working height
12 ft 6 in
Max. platform height
6 ft 6 in
Stowed height
5 ft 6 in
Platform capacity (SWL)
529 lbs
Overall width
2 ft 4 in
Overall length
3 ft 11 in
Max. wind speed
0 mph
Raise / lower time
8 / 14 sec
Power source
12V DC battery
Charger
Built in multi-voltage (90V - 240V)
Weight
682 lbs

Specifications subject to change without notice. The equipment hereunder have been subject to limited testing, and any performance specifications and representations are the result of limited testing. Photos and diagrams are shown for illustrative purposes only. Snorkel makes no warranty, representation, or guarantee regarding the information contained herein or the suitability of its equipment for any particular purpose. It is the Buyer’s responsibility to independently determine suitability of any equipment or parts, and to test and verify the same. Refer to appropriate Snorkel operator’s manual for detailed instructions on the proper use and maintenance.

Last Updated
01/2019

Standard Features

  • Auto brake system
  • Tilt sensor
  • Saloon-door style entry gates
  • Integrated battery charger 90V - 240V
  • Battery charge indicator
  • Forklift pockets
  • Emergency lowering system
  • Non-marking casters
  • Slide-out service trays
  • 2 year parts & labor, 5 year structural warranty

Options

  • Special paint colors
  • Environmental hydraulic oil
